Harnessed drive cables | Fanuc Harnessed drive cables | Fanuc
Fanuc Fanuc
PVC/PUR/TPE PVC/PUR/TPE

* Technical information on the cable quality (Code 01-31):  Page 578-581 * Technical information on the cable quality (Code 01-31):  Page 578-581

Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Fanuc Power cables Fanuc Servo cables

Basic cable Basic cable

LX660-8077-T296 LX660-8077-T470
PVC M.I. 01 MAT9760913 (4G2.5)C 11.5 7.5 PUR O.I. 06 MAT9850925 (4G4.0)C 12.5 10
PUR O.I. 06 MAT9200096 (4G2.5)C 10.5 10
PUR M.I. 07 MAT9210096 (4G2.5)C 12.5 7.5 Basic cable
TPE F 02 MAT9960913 (4G2.5)C 11.5 7.5
LX660-8077-T471
Basic cable PUR O.I. 06 MAT9850917 (4G4.0)C 12.5 10
Fanuc Brake cables
LX660-8077-T298
PVC M.I. 01 MAT9760914 (4G4.0)C 13.0 7.5 Basic cable
PUR O.I. 06 MAT9200098 (4G4.0)C 12.5 10
PUR M.I. 07 MAT9210098 (4G4.0+(2x1.5)C)C 16.0 7.5 LX660-8077-T311
TPE F 02 MAT9960914 (4G4.0)C 13.0 7.5 PUR M.I. 22 MAT9810919 (3G0.75)C 8.0 6.8
Fanuc Signal cables
Basic cable
Basic cable
LX660-8077-T300
PVC M.I. 01 MAT9760915 (4G2.5)C 11.5 7.5 LX660-2018-T015
PUR O.I. 06 MAT9200300 (4G2.5)C 10.5 10 PVC 14 MAT9840924 (10x(2x0.25))C 12.0 7.5
PUR M.I. 07 MAT9210300 (4G2.5)C 12.5 7.5
TPE F 02 MAT9960915 (4G2.5)C 11.5 7.5 Basic cable
Fanuc Servo cables
LX660-4077-T296
Basic cable PUR O.I. 09 MAT9300296 ((2x0.25)+5x0.5)C 7.0 10
PUR M.I. 10 MAT9840901 ((2x0.25)+5x0.5)C 8.0 7.5
LX660-8077-T259 TPE H* 11 MAT9310296 ((2x0.25)+5x0.5)C 7.5 6.8
PUR O.I. 06 MAT9850916 (4G1.5)C 9.0 10
Basic cable
Basic cable
LX660-4077-T297
LX660-8077-T274 PUR O.I. 09 MAT9300297 ((2x0.25)+5x0.5)C 7.0 10
PUR O.I. 06 MAT9850921 (4G2.5)C 10.5 10 PUR M.I. 10 MAT9840902 ((2x0.25)+5x0.5)C 8.0 7.5
LX660-8077-T416 TPE H* 11 MAT9310297 ((2x0.25)+5x0.5)C 7.5 6.8
PUR O.I. 06 MAT9850923 (4G1.5+(2x1.5)C) 12.5 10
LX660-8077-T451 Basic cable
PUR O.I. 06 MAT9850920 (4G2.5)C 10.5 10
LX660-4077-T302
PUR O.I. 09 MAT9300302 ((4x0.25)+3x(2x0.25+2x0.5))C 9.5 10

Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
