Nidec/ Harnessed drive cables | Nidec/Control Techniques Harnessed drive cables | Nidec/Control Techniques Nidec/
Control Control
Techniques Techniques
PVC/PUR PVC/PUR/TPE
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Nidec/Control Techniques Servo cables Nidec/Control Techniques Servo cables
PB B E F B XXX
Basic cable PVC M.I. 05 MAT9560057 (4G16+(2x1.5)C)C 25.0 7.5
PUR M.I. 07 MAT9540057 (4G16+(2x1.5)C)C 24.0 7.5
PB B B G B XXX PB B E G B XXX
PVC O.I. 04 MAT9750521 (4G4.0+(2x1.5)C)C 15.0 10 PVC M.I. 05 MAT9560069 (4G16+(2x1.5)C)C 25.0 7.5
PVC M.I. 05 MAT9560066 (4G4.0+(2x1.5)C)C 16.0 7.5 PUR M.I. 07 MAT9540069 (4G16+(2x1.5)C)C 24.0 7.5
PUR M.I. 07 MAT9540066 (4G4.0+(2x1.5)C)C 16.0 7.5 PB B G A B XXX
PB B C A B XXX PVC O.I. 04 MAT9750507 (4G1.5+(2x1.5)C) 12.5 10
PVC O.I. 04 MAT9750510 (4G6.0+(2x1.5)C)C 16.5 10 PVC M.I. 05 MAT9560046 (4G1.5+(2x1.5)C) 13.0 7.5
PVC M.I. 05 MAT9560049 (4G6.0+(2x1.5)C)C 18.0 7.5 PUR M.I. 07 MAT9540046 (4G1.5+(2x1.5)C) 13.0 7.5
PUR M.I. 07 MAT9540049 (4G6.0+(2x1.5)C)C 17.5 7.5 PB B G B B XXX
PB B C B B XXX PVC O.I. 04 MAT9750515 (4G1.5+(2x1.5)C) 12.5 10
PVC O.I. 04 MAT9750518 (4G6.0+(2x1.5)C)C 16.5 10 PVC M.I. 05 MAT9560058 (4G1.5+(2x1.5)C) 13.0 7.5
PVC M.I. 05 MAT9560061 (4G6.0+(2x1.5)C)C 18.0 7.5 PUR M.I. 07 MAT9540058 (4G1.5+(2x1.5)C) 13.0 7.5
PUR M.I. 07 MAT9540061 (4G6.0+(2x1.5)C)C 17.5 7.5 PB B G F B XXX
PB B C F B XXX PVC O.I. 04 MAT9750511 (4G1.5+(2x1.5)C) 12.5 10
PVC O.I. 04 MAT9750514 (4G6.0+(2x1.5)C)C 16.5 10 PVC M.I. 05 MAT9560052 (4G1.5+(2x1.5)C) 13.0 7.5
PVC M.I. 05 MAT9560055 (4G6.0+(2x1.5)C)C 18.0 7.5 PUR M.I. 07 MAT9540052 (4G1.5+(2x1.5)C) 13.0 7.5
PUR M.I. 07 MAT9540055 (4G6.0+(2x1.5)C)C 17.5 7.5 PB B G G B XXX
PB B C G B XXX PVC O.I. 04 MAT9750519 (4G1.5+(2x1.5)C) 12.5 10
PVC O.I. 04 MAT9750522 (4G6.0+(2x1.5)C)C 16.5 10 PVC M.I. 05 MAT9560064 (4G1.5+(2x1.5)C) 13.0 7.5
PVC M.I. 05 MAT9560067 (4G6.0+(2x1.5)C)C 18.0 7.5 PUR M.I. 07 MAT9540064 (4G1.5+(2x1.5)C) 13.0 7.5
PUR M.I. 07 MAT9540067 (4G6.0+(2x1.5)C)C 17.5 7.5 Nidec/Control Techniques Encoder cables
PB B D A B XXX
PVC M.I. 05 MAT9560050 (4G10+(2x1.5)C)C 21.5 7.5 Basic cable
PUR M.I. 07 MAT9540050 (4G10+(2x1.5)C)C 21.0 7.5
PB B D B B XXX SS B A H C XXX
PVC M.I. 05 MAT9560062 (4G10+(2x1.5)C)C 21.5 7.5 PVC 08 MAT9560100 (4x(2x0.34)+4x0.5)C 9.5 10
PUR M.I. 07 MAT9540062 (4G10+(2x1.5)C)C 21.0 7.5 PUR M.I. 10 MAT9840501 (4x(2x0.34)+4x0.5)C 10.0 7.5
PB B D F B XXX TPE H* 11 MAT9540100 (4x(2x0.34)+4x0.5)C 10.0 6.8
PVC M.I. 05 MAT9560056 (4G10+(2x1.5)C)C 21.5 7.5 SS B A H H XXX
PUR M.I. 07 MAT9540056 (4G10+(2x1.5)C)C 21.0 7.5 PVC 08 MAT9560101 (4x(2x0.34)+4x0.5)C 9.5 10
PB B D G B XXX PUR M.I. 10 MAT9840502 (4x(2x0.34)+4x0.5)C 10.0 7.5
PVC M.I. 05 MAT9560068 (4G10+(2x1.5)C)C 21.5 7.5 TPE H* 11 MAT9540101 (4x(2x0.34)+4x0.5)C 10.0 6.8
PUR M.I. 07 MAT9540068 (4G10+(2x1.5)C)C 21.0 7.5 SS B A H N XXX
PB B E A B XXX PVC 08 MAT9560104 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 9.0 10
PVC M.I. 05 MAT9560051 (4G16+(2x1.5)C)C 25.0 7.5 PUR M.I. 10 MAT9840505 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 7.5
PUR M.I. 07 MAT9540051 (4G16+(2x1.5)C)C 24.0 7.5 TPE H* 11 MAT9540104 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 6.8
PB B E B B XXX
PVC M.I. 05 MAT9560063 (4G16+(2x1.5)C)C 25.0 7.5
PUR M.I. 07 MAT9540063 (4G16+(2x1.5)C)C 24.0 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
®
®
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
