P. 736
Harnessed drive cables | NUM Harnessed drive cables | NUM
NUM NUM
PVC/PUR/TPE PVC/PUR/TPE
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
NUM Power cables NUM Servo cables
Basic cable Extension cable
AGOFRU018LMxxx AGOFRU018Mxxx (ext.)
PVC M.I. 01 MAT9280051 (4G1.5)C 10.0 7.5 PVC M.I. 05 MAT9280011 (4G1.5+(2x1.5)C) 13.0 7.5
TPE F 02 MAT9282051 (4G1.5)C 10.0 7.5 PUR M.I. 07 MAT9282011 (4G1.5+(2x1.5)C) 13.0 7.5
TPE H* 03 MAT9961201 (4G1.5)C 10.0 7.5 AGOFRU019Mxxx (ext.)
AGOFRU019LMxxx PVC M.I. 05 MAT9280012 (4G4.0+(2x1.5)C)C 16.0 7.5
PVC M.I. 01 MAT9280052 (4G4.0)C 13.0 7.5 PUR M.I. 07 MAT9282012 (4G4.0+(2x1.5)C)C 16.0 7.5
TPE F 02 MAT9282052 (4G4.0)C 13.0 7.5
TPE H* 03 MAT9961202 (4G4.0)C 13.0 7.5 Extension cable
Extension cable AGOFRU020Mxxx (ext.)
PVC M.I. 05 MAT9280013 (4G10+(2x1.5)C)C 21.5 7.5
AGOFRU018LMxxx (ext.) PUR M.I. 07 MAT9282013 (4G10+(2x1.5)C)C 21.0 7.5
PVC M.I. 01 MAT9280061 (4G1.5)C 10.0 7.5 NUM Fan cables
TPE H* 03 MAT9961203 (4G1.5)C 10.0 7.5
AGOFRU018LMxxx (ext.) Basic cable
TPE F 02 MAT9282061 (4G1.5)C 10.0 7.5
AGOFRU019LMxxx (ext.) AGOFRU012Mxxx
PVC M.I. 01 MAT9280062 (4G4.0)C 13.0 7.5 PVC 17 MAT9289005 4G1.0 7.0 7.5
TPE F 02 MAT9282062 (4G4.0)C 13.0 7.5 TPE H* 23 MAT9289007 4G1.0 6.5 5
TPE H* 03 MAT9961204 (4G4.0)C 13.0 7.5
NUM Servo cables Extension cable
Basic cable AGOFRU012Mxxx (ext.)
PVC 17 MAT9289015 4G1.0 7.0 7.5
AGOFRU018Mxxx TPE H* 23 MAT9289017 4G1.0 6.5 5
PVC M.I. 05 MAT9280001 (4G1.5+(2x1.5)C) 13.0 7.5 NUM Encoder cables
PUR M.I. 07 MAT9282001 (4G1.5+(2x1.5)C) 13.0 7.5
AGOFRU019Mxxx Basic cable
PVC M.I. 05 MAT9280002 (4G4.0+(2x1.5)C)C 16.0 7.5
PUR M.I. 07 MAT9282002 (4G4.0+(2x1.5)C)C 16.0 7.5 AGOFRU029Mxxx
PVC 08 MAT9284001 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 9.0 10
Basic cable TPE H* 11 MAT9286001 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 6.8
AGOFRU020Mxxx Basic cable
PVC M.I. 05 MAT9280003 (4G10+(2x1.5)C)C 21.5 7.5
PUR M.I. 07 MAT9282003 (4G10+(2x1.5)C)C 21.0 7.5 AGOFRU030Mxxx
PVC 08 MAT9289001 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 9.0 10
TPE H* 11 MAT9289004 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 6.8
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
