CONTEC TE/INTERCONTEC | Series B | Standard TE/INTERCONTEC | Series B | Speedtec CONTEC
Series B Series B

Example image Example image

Power connector [6 to 9-pole], nickel-plated (metal construction, EMC shielding) Power connector [6 to 9-pole], nickel-plated (metal construction, EMC shielding)
Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping tool Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping tool
(material) crimping range range + insert (material) crimping range range + insert
insert insert

[mm] [mm²] [mm] [mm] [mm²] [mm]
P type HC female P type HC female
MAT0179620 6x2.0 0.35-2.5 9.5-14.5 C 2 MAT01723481 6x2.0 0.35-2.5 9.5-14.5 C 2

6-pole crimp 6-pole crimp
HC female 4x2.0 0.35-2.5 HC female 4x2.0 0.35-2.5
P type crimp P type crimp
MAT0179621 9.5-14.5 C 2 1 MAT01723482 9.5-14.5 C 2 1

8-pole HC female 8-pole HC female
crimp 4x1.0 0.14-1 crimp 4x1.0 0.14-1
HC female 4x2.0 0.35-2.5 HC female 4x2.0 0.35-2.5
P type crimp P type crimp
MAT0179622 9.5-14.5 C 2 1 MAT01723483 9.5-14.5 C 2 1

9-pole HC female 9-pole HC female
crimp 5x1.0 0.14-1 crimp 5x1.0 0.14-1

Example image Example image
Bulkhead connector with union nut Bulkhead connector with union nut
Part No. Number of poles Crimping tool Part No. Number of poles Crimping tool
+ insert + insert

MAT0178406 6-pole C 2 MAT01723484 6-pole C 2

MAT0175661 8-pole C 2 1 MAT01723485 8-pole C 2 1

MAT0179033 9-pole C 2 1 MAT01723486 9-pole C 2 1

Crimping tools and inserts  Page 818 Crimping tools and inserts  Page 818
+
