CONTEC TE/INTERCONTEC | Series M17 | Standard TE/INTERCONTEC | Series M17 | Speedtec CONTEC
Series M17 Series M17

Example image Example image

Signal connector [17-pole], nickel-plated (metal construction, EMC shielding) Signal connector [17-pole], nickel-plated (metal construction, EMC shielding)
Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping
(material) crimping range range tool (material) crimping range range tool
insert + insert insert + insert

[mm] [mm²] [mm] [mm] [mm²] [mm]

P type Female crimp, P type Female crimp,
MAT0179639 17x0.6 0.14-0.5 9.5-12.0 B MAT01723493 17x0.6 0.14-0.5 9.5-12.0 B
17 pole slotted 17 pole slotted

Example image Example image

Signal coupling [17-pole], nickel-plated (metal construction, EMC shielding) Signal coupling [17-pole], nickel-plated (metal construction, EMC shielding)
Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping
(material) crimping insert range range tool + insert (material) crimping insert range range tool + insert
[mm] [mm²] [mm] [mm] [mm²] [mm]
E type E type
MAT0179640 Male crimp 17x0.6 0.14-0.5 9.5-12.0 B MAT01723494 Male crimp 17x0.6 0.14-0.5 9.5-12.0 B
17 pole 17 pole

+
Crimping tools and inserts  Page 818 Crimping tools and inserts  Page 818
