BINDER
HARTING Connectors
HARTING | Connector sets Premium (pin + socket) BINDER | Series 768

Electrical information series 768
HARTING Connector sets Premium, pin + socket Number of poles 3 4
Part No. Cable Insert Pin insert - Socket insert - Connector Connector 2 2
entry manufacturer manufacturer housing - base - Terminal cross section 0.14mm – 0.5mm (AWG26–AWG20)
Part No. Part No. manufacturer manufacturer Mechanical service life > 100 insertion cycles
Part No. Part No. Temperature limit –40°C up to +80°C
Rated voltage 60V (30V UL)

Pollution degree 3
Han 6B connector housing Rated current (40°C) 4A
and base, straight cable entry Contact surface Au (gold)
Housing material PBT/PA/CuZn (brass)
MAT90489818.U M20 6+PE 09330062601 09330062701 19300061440 19300061250
Binder connector M8 – A-coded, screw connection
Han 6B connector housing Part No. Manufacturer Part No. Number of poles Contact type Clamping range
and base, angled cable entry
[mm]
MAT90489819.U M20 6+PE 09330062601 09330062701 19300061540 19300061250
Han 10B connector housing
and base, straight cable entry

MAT90489820.U M25 10+PE 09330102601 09330102701 19300101441 19300101250
Binder M8 cable socket
Han 10B connector housing
and base, angled cable entry MAT0174945 99 3400 100 03 3-pole Socket 3.5-5.0
MAT0174989 99 3376 100 04 4-pole Socket 3.5-5.0
MAT90489821.U M25 10+PE 09330102601 09330102701 19300101541 19300101250

Han 16B connector housing
and base, straight cable entry

MAT90489822.U M25 16+PE 09330162601 09330162701 19300161441 19300161251
Binder M8 cable connector
Han 16B connector housing
and base, angled cable entry MAT01712009 99 3379 100 03 3-pole Pin 3.5-5.0
MAT0173041 99 3383 100 04 4-pole Pin 3.5-5.0
MAT90489823.U M25 16+PE 09330162601 09330162701 19300161541 19300161251

Han 24B connector housing
and base, straight cable entry

MAT90489824.U M32 24+PE 09330242601 09330242701 19300241442 19300241251

Han 24B connector housing Binder M8 cable socket, shielded
and base, angled cable entry MAT01747828 99 3360 100 03 3-pole Socket 4.0-5.5
MAT01743277 99 3362 100 04 4-pole Socket 4.0-5.5
MAT90489825.U M32 24+PE 09330242601 09330242701 19300241542 19300241251
MAT01733873 99 3360 300 03 3-pole Socket 6.0-8.0
MAT01731011 99 3362 300 04 4-pole Socket 6.0-8.0

Binder M8 cable connector, shielded

MAT01715998 99 3361 100 03 3-pole Pin 4.0-5.5
MAT01717508 99 3363 100 04 4-pole Pin 4.0-5.5
MAT01733874 99 3361 300 03 3-pole Pin 6.0-8.0
ASEAN2023 ASEAN2023 MAT01730059 99 3363 300 04 4-pole Pin 6.0-8.0
