BINDER | Series 713 BINDER | Series 713

Electrical information series 713 plastic Binder connector M12 – A-coded, screw connection
Part No. Part No. Number of poles Contact type Clamping range
Number of poles 3 4 5 8 [mm]
2
2
Terminal cross section max. 0.75mm (AWG 20) max. 0.5mm (AWG 20)
Mechanical service life > 50 insertion cycles > 100 insertion cycles
Temperature limit -40°C up to +85°C, outdoor -40°C up to +100°C
Rated voltage 250V 60V 30V
Pollution degree 3
Rated current (40°C) 4A 2A
Contact surface CuSnZn (Optalloy) Au (gold) Binder M12 cables socket, shielded
Housing material PA
MAT0171842 99 1430 812 04 4-pole Socket 4.0-6.0
MAT0173023 99 1436 812 05 5-pole Socket 6.0-8.0
Electrical information series 713 metal MAT01749490 99 1436 914 05 5-pole Socket 8.0-10.0
MAT0176266 99 1486 812 08 8-pole Socket 6.0-8.0
Number of poles 4 5 8
2
Terminal cross section max. 0.75mm (AWG 20) max. 0.5mm (AWG 20) MAT01724437 99 1486 914 08 8-pole Socket 8.0-10.0
2
Mechanical service life > 100 insertion cycles
Temperature limit -40°C up to +85°C
Rated voltage 250V 60V 30V
Pollution degree 3
Rated current (40°C) 4A 2A
Contact surface Au (gold) Binder M12 cable connector, shielded
Housing material straight: CuZn (brass, nickel-plated), angled: zinc die-casting, nickel-plated
MAT0171841 99 1429 812 04 4-pole Pin 4.0-6.0
MAT0170880 99 1437 812 05 5-pole Pin 6.0-8.0
Binder connector M12 – A-coded, screw connection MAT01749489 99 1437 914 05 5-pole Pin 8.0-10.0
Part No. Part No. Number of poles Contact type Clamping range MAT0176267 99 1487 812 08 8-pole Pin 6.0-8.0
[mm] MAT01729497 99 1487 914 08 8-pole Pin 8.0-10.0

Binder connector M12 – A-coded, angled sockets, screw connection
Part No. Part No. Number of poles Contact type Clamping range
[mm]
Binder M12 cable socket

MAT01717316 99 0430 07 04 3-pole Socket 4.0-6.0
MAT01715145 99 0430 12 04 4-pole Socket 6.0-8.0
MAT0175659 99 0436 12 05 5-pole Socket 6.0-8.0
MAT0178575 99 0486 12 08 8-pole Socket 6.0-8.0
Binder M12 angled socket

MAT0172523 99 1430 822 04 4-pole Socket 6.0-8.0
MAT01717529 99 1436 822 05 5-pole Socket 6.0-8.0

Binder M12 connector
MAT0173490 99 0429 07 04 3-pole Pin 4.0-6.0
MAT01710555 99 0429 12 04 4-pole Pin 6.0-8.0 Binder M12 angled connector shielded
MAT01718305 99 0437 12 05 5-pole Pin 6.0-8.0
MAT01710219 99 0487 12 08 8-pole Pin 6.0-8.0 MAT01725700 99 1429 822 04 4-pole Pin 6.0-8.0
MAT01727838 99 1437 822 05 5-pole Pin 6.0-8.0
