chainfix chainfix strain relief | Clip-on solutions chainfix strain relief | Clip-on solutions chainfix
Product range | Installation dimensions

Strain relief separators - separators with integrated strain
relief teeth
®
● To be fitted at the first and last e-chain link
● For restricted space conditions
● Easy to assemble without any screws
● The number n depends on the selection of the cables
(diameter, type) and the available space

Strain relief separator | With integrated teeth Strain relief separator | Product range | Installation dimensions For the following
igus series
®
Part No. For Number A B C D E2.1
series of teeth [mm] [mm] [mm] [mm] ● E2.26
26.Z* E2.26 6 12 3 – 7 E2/000
21.1.Z 1400/1500 4 10 4 – 6 ● 1400/1500
2020.Z 2400/2500 2 10 4 – 6 ● 2400/2500
2020.ZR 2450/2480 4 10 4 – 6 ● 2450/2480
262.Z 2600/2700 3 10 4 – 6 ● 2600/2700
301.Z 3400/3500 3 18 4 – 14 ● 3400/3500
34501.Z 3450/3480 6 14 4 – 10 ● 3450/3480
1585.01.Z R157/R158 6 22 4 – 18 E2 R100
1685.01.Z R167/R168 8 22 4 – 18 ● R157/R158
481.ZR R48 4 10 3.5 10 6.5 ● R167/R168
R2.26.Z R2.26/R2.26i 4 10 3 – 6 E2 R
R2.40.Z R2.40/R2i.40 8 12 3 – 7 ● R48
Strain relief separators are assembled either at the first or last e-chain link. Alternatively they can be fitted within the e-chain as 31.Z E4.31L/R4.31L 4 9 4 6 6 R2.1
®
®
an intermediate strain relief 38.Z E4.38L/R4.38L 4 14 4.5 8 15 ● R2.26/R2i.26
48.Z E4.48L/R4.48L 4 14 4.5 8 20 ● R2i.40/R2i.40
48.ZS E4.48L/R4.48L 4 14 4.5 8 20 E4.1L
T2103.Z E4.21 2 8 4 1 4 ● E4.31L/R4.31L
28.Z E4.28 4 10 4 – 6 ● E4.38L/R4.38L
28.ZT R4.28 4 10 4 15 6 ● E4.48L/R4.48L
E6.29.02.Z T3.29 2 8 4 1 4 E4.1
E6.29.02.Z E6.29/E61.29 2 8 4 1 4 ● E4.21
R6.29.02.Z R6.29 2 10 4 10 4 ● E4.28/R4.28
E6.35.02.Z E6.35/E61.35 3 8 4 1 4 T3
E6.40.02.Z E6.40/E61.40 3 13 4 – 8 ● T3.29
*For KMA mounting bracket only E6.1
● E61.29/EF61.29
● E61.35
● E61.40
E6
● E6.29
● R6.29
● E6.35
ASEAN2023 ASEAN2023 ● E6.40

902 More information www.igus-asean.com/cfx_separator 3D-CAD, configurators, service life calculation and more www.igus-asean.com/chainfix 903
