chainfix chainfix strain relief | Clip-on solutions chainfix strain relief | Clip-on solutions chainfix
Strain relief separator | Overview Strain relief separator | Overview

For series E2/000 For series R100 E2 e-tubes For series E4.1L For series T3

1400/1500 R157/R158 E4.31L/R4.31L T3.29
e-chains ® e-tubes e-chains /e-tubes e-chains ®
®
unassembled 21.1.Z unassembled 1585.01.Z unassembled 31.Z unassembled E6.29.02.Z
assembled 21.1.Z.1 assembled 1586.01.Z assembled 31.Z.1 assembled E6.29.12.Z

2400/2500 R167/R168 E4.38L/R4.38L
e-chains ® e-tubes e-chains /e-tubes For series E6.1 / E6 / R6
®
unassembled 2020.Z unassembled 1685.01.Z unassembled 38.Z E6.29/E61.29
assembled 2120.Z assembled 1686.01.Z New assembled 38.Z.1 e-chains ®
unassembled E6.29.02.Z
2450/2480 E4.48L/R4.48L assembled E6.29.12.Z
e-tubes For series R E2 e-tubes e-chains /e-tubes
®
unassembled 2020.ZR R48 unassembled 48.Z R6.29
assembled 2120.ZR e-tubes assembled 48.Z.1 e-tubes
unassembled 481.ZR unassembled R6.29.02.Z
2600/2700 assembled 482.ZR E4.48L/R4.48L assembled R6.29.12.Z
e-chains ® e-chains /e-tubes
®
unassembled 262.Z unassembled 48.ZS E6.35/E61.35
assembled 263.Z assembled 48.ZS.1 e-chains ®
For series R2.1 e-tubes
unassembled E6.35.02.Z
3400/3500 R2.26·R2i.26 assembled E6.35.12.Z
e-chains ® e-tubes For series E4.1
unassembled 301.Z unassembled R2.26.Z E4.28 E6.40/E61.40
assembled 311.Z assembled R2.26.Z.1 e-chains ® e-chains ®
unassembled 28.Z unassembled E6.40.02.Z
3450/3480 R2.40·R2i.40 assembled 28.Z.1 assembled E6.40.12.Z
e-tubes e-tubes
unassembled 34501.Z unassembled R2.40.Z R4.28
assembled 34511.Z assembled R2.40.Z.1 e-tubes
unassembled 28.ZT
assembled 28.ZT.1
For series E2.1 e-chains ®
E2.26·E2i.26* E4.21
e-chains ® e-chains ®
unassembled 26.Z unassembled T2103.Z
assembled 26.Z.1 assembled T2113.Z

*For KMA mounting bracket only
