2Product Dimension
Nominal Block Dimensions (mm)
model W B B1 C L1 L2 K1 K2 G M T H2 H3
20 63 53 5.5 40 65.2 92.2 17.6 M6 6
8 6
25 70 57 6.5 45 78.6 104.6 21 6 12 M8 5 2
30 90 72 9 52 93 120.4 25.75 M10 8.5 6.5 10.8
Nominal Guide Rail Dimensions (mm) Guide Rail Fixing Bolt
model WR HR D h d P E Dimensions (mm) Bushings / Oil Free Bushings Linear Guides / Linear
20 20 17.5 9.5 8.5 6 M5×16
60 Please refer to
25 23 22 11 9 7 the calculation M6×20
table below
30 28 26 14 12 9 80 M8×25
&Since this product has no surface treatment, please be sure to take anti-rust measures. Linear Guides Miniature
&Dimension tolerance of L Length is ±2 mm.
&The kit includes 1 block. For additional blocks, please purchase a single block model.
P.113
2Allowable Load 2E Dimension
Basic Rated Load Static Allowable Moment Mass L : Guide Rail length
Nominal M : Guide Rail mounting holes Guides Linear
model C (Dynamic) Co (Static) MA·MB MC Blocks Guide Rails P : Guide Rail holes pitch
kN kN kN·m kN·m kg kg/m L-(M-1)×P
20 32.7 47.96 0.35 0.35 0.52 2.11 E= 2
25 42.2 69.07 0.57 0.56 0.8 3.21 Number of P.123
30 58.6 93.99 0.92 0.88 1.44 4.47 H 30 36 42 Mounting
Holes M Bushings
Example 110~139 160~201 160~199 2 Linear
140~199 202~261 200~279 3
200~259 262~321 280~343 4 P.139
260~319 322~381 344~423 5
320~379 382~441 424~503 6
380~439 442~501 504~583 7 Bushings Oil Free
440~499 502~561 584~663 8
500~559 562~621 664~743 9
560~619 622~681 744~823 10 P.161
620~679 682~741 824~903 11
680~739 742~801 904~983 12 Supports Shaft
740~799 802~861 984~1063 13
800~859 862~921 1064~1143 14
860~919 922~981 1144~1223 15 P.170
920~979 982~1041 1224~1303 16
980~1039 1042~1101 1304~1383 17
L
1040~1099 1102~1161 1384~1463 18 Collars Shaft
1100~1159 1162~1221 1464~1543 19
1160~1219 1222~1281 1544~1623 20
1220~1279 1282~1341 1624~1703 21 P.173
1280~1339 1342~1401 1704~1783 22
1340~1399 1402~1461 1784~1863 23
2-stages stroke type block 1400~1459 1462~1521 1864~1943 24
The 2-stages sliding mechanism is used to 1460~1519 1522~1581 1944~1960 25
automatically store the workpiece received by the
adsorption mechanism in the cavity, and the linear 1520~1579 1582~1641 26
guide is used to compensate for the torque load of 1580~1639 1642~1701 27
the cylinder. 1640~1699 1702~1761 28
1700~1759 1762~1821 - 29
1760~1819 1822~1881 30
1820~1879 1882~1941 31
1880~1939 1942~1960 32
1940~1960 - 33
P 60 80
