Page 137 - MiSUMi FA Mechanical Components Economy Series
P. 137

2Product Dimension
             Nominal                              Block Dimensions (mm)
             model    W     B     B1    C     L1    L2    K1    K2    G    M×-    T     H2    H3
               20     44    32    5          65.2  92.2  12.6              M5×6         6     6
                                        50                                        8
               25     48    35    6.5        78.6  104.6  18.5  6     12   M6×8         10    9       2
               30     60    40    10    60    93   120.4  21.75           M8×10  8.5   9.5   13.8
             Nominal                    Guide Rail Dimensions (mm)               Guide Rail Fixing Bolt
             model     WR      HR       D       h       d       P         E        Dimensions (mm)   Bushings / Oil Free Bushings  Linear Guides / Linear
               20      20      17.5    9.5     8.5      6                              M5×16
                                                                60    Please refer to
               25      23      22      11       9       7             the calculation   M6×20
                                                                       table below
               30      28      26      14       12      9       80                     M8×25
           &Since this product has no surface treatment, please be sure to take anti-rust measures.  Linear Guides  Miniature
           &Dimension tolerance of L Length is ±2 mm.
           &The kit includes 1 block. For additional blocks, please purchase a single block model.
                                                                                                    P.113
           2Allowable Load                             2E Dimension
                 Basic Rated Load Static Allowable Moment  Mass  L  : Guide Rail length
           Nominal                                     M : Guide Rail mounting holes                 Guides  Linear
            model  C (Dynamic)  Co (Static)  MA·MB  MC  Blocks Guide Rails  P : Guide Rail holes pitch
                    kN   kN    kN·m  kN·m   kg    kg/m     L-(M-1)×P
             20    32.7  47.96  0.35  0.35  0.39  2.21  E=    2
             25    42.2  69.07  0.57  0.56  0.69  3.21                                       Number of   P.123
             30    58.6  93.99  0.92  0.88  1.16  4.47  H      30         40          45     Mounting
                                                                                             Holes M  Bushings
                Example                                      100~139    160~201       -       2       Linear
                                                             140~199    202~261     200~279   3
                                                             200~259    262~321     280~343   4     P.139
                                                             260~319    322~381     344~423   5
                                                             320~379    382~441     424~503   6
                                                             380~439    442~501     504~583   7      Bushings  Oil Free
                                                             440~499    502~561     584~663   8
                                                             500~559    562~621     664~743   9
                                                             560~619    622~681     744~823   10    P.161
                                                             620~679    682~741     824~903   11
                                                             680~739    742~801     904~983   12     Supports  Shaft
                                                             740~799    802~861    984~1063   13
                                                             800~859    862~921    1064~1143  14
                                                             860~919    922~981    1144~1223  15    P.170
                                                             920~979    982~1041   1224~1303  16
                                                            980~1039   1042~1101   1304~1383  17
                                                        L
                                                            1040~1099  1102~1161   1384~1463  18     Collars  Shaft
                                                            1100~1159  1162~1221   1464~1543  19
                                                            1160~1219  1222~1281   1544~1623  20
                                                            1220~1279  1282~1341   1624~1703  21    P.173
                                                            1280~1339  1342~1401   1704~1783  22
                                                            1340~1399  1402~1461   1784~1863  23
               Traverse mechanism for heavy workpieces      1400~1459  1462~1521   1864~1943  24
               A mechanism that rotates a servo motor to move a   1460~1519  1522~1581  1944~1960  25
               pallet horizontally.
               A traverse mechanism that supports the load by the   1520~1579  1582~1641  -   26
               linear guide and reduces the transmission power.  1580~1639  1642~1701  -      27
                                                            1640~1699  1702~1761      -       28
                                                            1700~1759  1762~1821      -       29
                                                            1760~1819  1822~1881      -       30
                                                            1820~1879  1882~1941      -       31
                                                            1880~1939  1942~1960      -       32
                                                            1940~1960      -          -       33
                                                        P            60               80
