2Product Dimension
             Nominal                              Block Dimensions (mm)
             model    W     B     B1    C     L1    L2    K1    K2    G     M     T     H2    H3
               15     52    41    5.5   26   39.8  56.8  10.15  3.5   5.7  M5     5    5.5
                                                                                              6
               20     59    49    5     32   48.1  69.1  12.3  4.15        M6     7     6             2
               25     73    60    6.5   35   35.5  82.6  16.15  4.55  12   M8    7.5          8
                                                                                        8
               30     90    72    9     40   70.1  98.1  21.05  6          M10    7           9
             Nominal                    Guide Rail Dimensions (mm)               Guide Rail Fixing Bolt
             model     WR      HR       D       h       d       P         E        Dimensions (mm)   Bushings / Oil Free Bushings  Linear Guides / Linear
               15      15      12.5     6      4.5     3.5                             M3×16
               20      20      15.5    9.5     8.5      6       60    Please refer to   M5×16
                                                                      the calculation
               25      23      18                                      table below     M6×20
                                       11       9       7
               30      28      23                               80                     M6×25
           &Since this product has no surface treatment, please be sure to take anti-rust measures.  Linear Guides  Miniature
           &Dimension tolerance of L Length is ±2 mm.
           &The kit includes 1 block. For additional blocks, please purchase a single block model.
                                                                                                    P.113
           2Allowable Load                             2E Dimension
                 Basic Rated Load Static Allowable Moment  Mass  L  : Guide Rail length
           Nominal                                     M : Guide Rail mounting holes                 Guides  Linear
            model  C (Dynamic)  Co (Static)  MA·MB  MC  Blocks Guide Rails  P : Guide Rail holes pitch
                    kN   kN    kN·m  kN·m   kg    kg/m     L-(M-1)×P
             15    7.83  16.19  0.1  0.13  0.21  1.25  E=     2
             20   10.31  21.13  0.16  0.22  0.32  2.08                                       Number of   P.123
             25   16.27  32.4  0.32  0.38  0.59  2.67   H     24      28       33      42    Mounting
             30    23.7  47.46  0.55  0.68  1.04  4.35                                       Holes M  Bushings
                                                           100~131  100~139  100~141    -     2       Linear
                                                           132~191  140~199  142~201  200~279  3
                Example                                    192~251  200~259  202~261  280~343  4    P.139
                                                            252~311  260~319  262~321  344~423  5
                                                           312~371  320~379  322~381  424~503  6
                                                           372~431  380~439  382~441  504~583  7     Bushings  Oil Free
                                                           432~491  440~499  442~501  584~663  8
                                                           492~551  500~559  502~561  664~743  9
                                                            552~611  560~619  562~621  744~823  10  P.161
                                                           612~671  620~679  622~681  824~903  11
                                                           672~731  680~739  682~741  904~983  12    Supports
                                                           732~791  740~799  742~801  984~1063  13    Shaft
                                                           792~851  800~859  802~861  1064~1143  14
                                                            852~911  860~919  862~921  1144~1223  15  P.170
                                                           912~971  920~979  922~981 1224~1303  16
                                                           972~1031 980~1039 982~1041 1304~1383  17
                                                        L
                                                           1032~1091 1040~1099 1042~1101 1384~1463  18  Collars  Shaft
                                                           1092~1151 1100~1159 1102~1161 1464~1543  19
                                                           1152~1211 1160~1219 1162~1221 1544~1623  20
                                                           1212~1271 1220~1279 1222~1281 1624~1703  21  P.173
                                                           1272~1331 1280~1339 1282~1341 1704~1783  22
                                                           1332~1391 1340~1399 1342~1401 1784~1863  23
               Precision visual inspection mechanism using the   1392~1451 1400~1459 1402~1461 1864~1943  24
               camera                                      1452~1511 1460~1519 1462~1521 1944~1960  25
               It uses the linear guide to fi x the workpiece and move
               it to ensure the working space. The image on the   1512~1571 1520~1579 1522~1581  -  26
               monitor is then visually inspected through the camera.  1572~1631 1580~1639 1582~1641  -  27
                                                           1632~1691 1640~1699 1642~1701  -   28
                                                           1692~1751 1700~1759 1702~1761  -   29
                                                           1752~1811 1760~1819 1762~1821  -   30
                                                           1812~1871 1820~1879 1822~1881  -   31
                                                           1872~1931 1880~1939 1882~1941  -   32
                                                           1932~1960 1940~1960 1942~1960  -   33
