2Product Dimension
             Nominal                              Block Dimensions (mm)
             model    W     B     B1    C     L1    L2    K1    K2    G    M×M    T     H2    H3
               15     34    26    4          23.1  40.1  14.8   3.5   5.7  M4×6   6    5.5
                                                                                              6
               20     42    32    5           29    50   18.75  4.15       M5×7  7.5    6
                                         -                                                            2
               25     48    35    6.5        35.5  59.1  21.9  4.55   12   M6×9   8           8
                                                                                        8
               30     60    40    10         41.5  69.5  26.75  6         M8×12   9           9
             Nominal                    Guide Rail Dimensions (mm)               Guide Rail Fixing Bolt
             model     WR      HR       D       h       d       P         E        Dimensions (mm)   Bushings / Oil Free Bushings  Linear Guides / Linear
               15      15      12.5     6      4.5     3.5                             M3×16
               20      20      15.5    9.5     8.5      6       60    Please refer to   M5×16
                                                                      the calculation
               25      23      18                                      table below     M6×20
                                       11       9       7
               30      28      23                               80                     M6×25
           &Since this product has no surface treatment, please be sure to take anti-rust measures.  Linear Guides  Miniature
           &Dimension tolerance of L Length is ±2 mm.
           &The kit includes 1 block. For additional blocks, please purchase a single block model.
                                                                                                    P.113
           2Allowable Load                             2E Dimension
                 Basic Rated Load Static Allowable Moment  Mass  L  : Guide Rail length
           Nominal                                     M : Guide Rail mounting holes                 Guides  Linear
            model  C (Dynamic)  Co (Static)  MA·MB  MC  Blocks Guide Rails  P : Guide Rail holes pitch
                    kN   kN   kN·m  kN·m   kg    kg/m      L-(M-1)×P
             15    5.35  9.4   0.04  0.08  0.09  1.25  E=     2
             20    7.23  12.74  0.06  0.13  0.15  2.08                                       Number of   P.123
             25    11.4  19.5  0.12  0.23  0.25  2.67   H     24      28       33      42    Mounting
             30   16.42  28.1  0.21  0.4  0.45  4.35                                         Holes M  Bushings  Linear
                                                           100~131  100~139  100~141    -     2
                                                           132~191  140~199  142~201  200~279  3
                Example                                    192~251  200~259  202~261  280~343  4    P.139
                                                            252~311  260~319  262~321  344~423  5
                                                           312~371  320~379  322~381  424~503  6
                                                           372~431  380~439  382~441  504~583  7     Bushings  Oil Free
                                                           432~491  440~499  442~501  584~663  8
                                                           492~551  500~559  502~561  664~743  9
                                                            552~611  560~619  562~621  744~823  10  P.161
                                                           612~671  620~679  622~681  824~903  11
                                                           672~731  680~739  682~741  904~983  12    Supports  Shaft
                                                           732~791  740~799  742~801  984~1063  13
                                                           792~851  800~859  802~861  1064~1143  14
                                                            852~911  860~919  862~921  1144~1223  15  P.170
                                                           912~971  920~979  922~981 1224~1303  16
                                                           972~1031 980~1039 982~1041 1304~1383  17
                                                        L
                                                           1032~1091 1040~1099 1042~1101 1384~1463  18  Collars  Shaft
                                                           1092~1151 1100~1159 1102~1161 1464~1543  19
                                                           1152~1211 1160~1219 1162~1221 1544~1623  20
                                                           1212~1271 1220~1279 1222~1281 1624~1703  21  P.173
                                                           1272~1331 1280~1339 1282~1341 1704~1783  22
                                                           1332~1391 1340~1399 1342~1401 1784~1863  23
               Section vibration measuring fi xture         1392~1451 1400~1459 1402~1461 1864~1943  24
               Move to the measuring position through the linear   1452~1511 1460~1519 1462~1521 1944~1960  25
               guide, and then measure the amplitude through the
               motor speed workpiece                       1512~1571 1520~1579 1522~1581  -   26
                                                           1572~1631 1580~1639 1582~1641  -   27
                                                           1632~1691 1640~1699 1642~1701  -   28
                                                           1692~1751 1700~1759 1702~1761  -   29
                                                           1752~1811 1760~1819 1762~1821  -   30
                                                           1812~1871 1820~1879 1822~1881  -   31
                                                           1872~1931 1880~1939 1882~1941  -   32
                                                           1932~1960 1940~1960 1942~1960  -   33
