           2Categories of use                                                              Unit: mm
                                                                     Maximum screw shaft runout tolerance  Lead Screws / Actuators  Ball Screws /
                                                Accuracy Grade
                                                                     (please see the table below for details)
                 MISUMI Economy series               C7                          0.350
                 MISUMI standard product                                         0.150
           Screw shaft runout tolerance                                                               Ball Screws
                                       G
                                                                     Screw shaft overall length
                                                              ~200   201~315 316~400 401~500 501~630  P.31
                                                       MISUMI
                                                       Economy   0.120  0.160  0.210  0.270  0.350
           MAX10                        MAX10           series                                       Ball Screws  Precision
           (Incomplete                 (Incomplete   G  MISUMI
            Hardened Area)              Hardened Area)  standard   0.065  0.080  0.100  0.120  0.150
                                                       product                                       P.49
                Alteration

           2Support side                               2Fixed side                                   for Ball Screw  Support Units
                 Alterations            Spec.                 Alterations            Spec.
              No Machining on Support Side                Wrench Flats on Fixed Side  Adds wrench fl ats on the fi xed side   P.61
             Shaft End                                                     shaft end.
                 Standard       No machining added on the support          &  Ball bearings will fall out if the ball
                                side shaft end.                 5  5         nut crosses the wrench flats.
                                                              0
             When machining                                  8-0.2  30                               Brackets  Motor
                is specified  L                                            &  The nut may not be moved within
                                                        Incomplete Hardened Area  the Incomplete Hardened Area
              Ball Nut Orientation Reversed               Keyway on Fixed Side Shaft   Adds a keyway on the fi xed side shaft
                                                         End %P.33         end.                      P.69
               (Support side)  (Fixed side)
                                Changes the nut direction.                 2≤KC≤8
              Standard                                           -0.004  -0.029  When specifi ed simultaneously with
               Change                                             2         , 2≤KC≤F-1                Lead Screws
                                                             KC     1.2    9P = 5 is not applicable
              No Retaining Ring Groove on                                  KC = 1mm increments
             Support Side Shaft End                       Machining fi xed side shaft end   The machining position of keyways at
                                No Retaining Ring Groove on Support   keyways  fi xed side shaft end can be specifi ed.   P.71
                  Standard
              When machining    Side Shaft End.                            (Keyway size is the same as KC.)
                  is specified                                             2≤K≤7  K+S≤8
                                                                           When specifi ed simultaneously with   Nuts
              Change Support Side Shaft                        K   S        ,  2≤K≤16                 Lead Screw
             End Length         Change the length of the support side        K+S≤F-1
                                shaft end.                                 9P = 5 is not applicable
                                                                           K, S = 1mm increments
                                10≤FC≤20                                                             P.83
                      6.8       FC = 1mm increments       Flat Machined on Fixed Side   Adds a fl at on the fi xed side shaft end
                   FC                                    Shaft End         5≤SC≤8
                                                                           When specifi ed simultaneously with
           & Only one of  ,   and   can be selected.          SC   0.5      , 5≤SC≤F-1               Support Units   Lead Screw
           & Only one of  ,   and   can be selected.                       SC = 1mm increments
           &    and   cannot be specifi ed simultaneously.     No machining of small steps on
           & When 2 and 8 are specifi ed simultaneously, no male thread will be   the fi xed side
             machined regardless of the value specifi ed for U in 2.                                  P.86
           & When 2 or 8 is specifi ed, the recommended support unit may not be   Standard  No machining of small steps on the
             available. Please reconfi rm.                   Change         fi xed side
           & When specifying any alteration, the nut motion range (Y dimension) may
             become shorter. Please make sure that the nut motion range is greater   L               Stop Plates  Lead Screw
             than the full length of the nut.              Change dimensions of small
                                                         steps on the fi xed side
                                                                           Change dimensions of small steps on
                                                        Recommended                                  P.90
                                                                           the fi xed side
                                                                           9≤F≤18  5≤P≤6
                                                                    P
                                                                           F, P = 1mm increments
                                                                 F                                    Actuators
                                                       2  Change dimensions of big
                                                         steps on the fi xed side
                                                                           Change dimensions of big steps on   P.99
                                                         Recommended       the fi xed side
                                                                 U         11≤E≤35  8≤U≤E-3
                                                                           E, U = 1mm increments
                                                                 E
                                                       8  No machining of big steps male
                                                        thread on the fi xed side
                                                                           No machining of big steps male
                                                            Standard       thread on the fi xed side
                                                            Change
