P. 39

1


           2Categories of use                                                              Unit: mm
                                                                     Maximum screw shaft runout tolerance  Lead Screws / Actuators  Ball Screws /
                                                Accuracy Grade
                                                                      (please see the table below for details)
                 MISUMI Economy series               C7                          0.270
                 MISUMI standard product                                         0.100
           Screw shaft runout tolerance                                                               Ball Screws
                                        G
                                                                       Screw shaft overall length    P.31
                                                                   ~125   126~200  201~315  316~400
           MAX10                         MAX10           MISUMI    0.100   0.140   0.210   0.270     Ball Screws  Precision
           (Incomplete                   (Incomplete   G  Economy series
            Hardened Area)               Hardened Area)  MISUMI    0.060   0.075   0.100     -
                                                       standard product                              P.49
                Alteration

           2Support side                               2Fixed side                                   for Ball Screw  Support Units
                 Alterations            Spec.                Alterations            Spec.
              No Machining on                             Wrench Flats on Fixed   Adds wrench fl ats on the fi xed   P.61
             Support Side Shaft End                      Side              side shaft end.
             Standard           No machining added on the                  &  Ball bearings will fall out if the
                                                                             ball nut crosses the wrench flats.
            When                support side shaft end.      0     4 4     &  The nut may not be moved   Brackets  Motor
            machining                                       5 -0.2  28       within the Incomplete
            is specified  L
                                                       Incomplete Hardened Area  Hardened Area       P.69
             Ball Nut Orientation Reversed                Flat Machined on Fixed
                                                         Side Shaft End    Adds a fl at on the fi xed side
             (Support side)  (Fixed side)                                  shaft end
                                                                           5≤SC≤7                     Lead Screws
           Standard             Changes the nut direction                  When specifi ed simultaneously
                                                           SC      0.5
            Change                                                         with  , 5≤SC≤F-1
                                                                           SC = 1mm increments       P.71
              No Retaining Ring                          No machining of small
             Groove on Support Side                      steps on the fi xed side                     Nuts
             Shaft End                                   Standard          No machining of small steps   Lead Screw
               Standard         No Retaining Ring Groove on                on the fi xed side
                                Support Side Shaft End.
              When                                        Change                                     P.83
              machining                                             L
              is specified
                                                         Change dimensions of
              Change Support Side                        small steps on the fi xed                    Support Units   Lead Screw
             Shaft End Length   Change the length of the   side            Change dimensions of small
                                support side shaft end.  Recommended       steps on the fi xed side
                                10≤FC≤20                                 P  8≤F≤13  4≤P≤5            P.86
                    6.8         FC = 1mm increments                        F, P = 1mm increments
                 FC                                                  F
           & Only one of  ,   and   can be selected.      Change dimensions of                       Stop Plates  Lead Screw
           & Only one of   and   can be selected.        big steps on the fi xed   Change dimensions of big
           & When   and   are specifi ed simultaneously, no male   side     steps on the fi xed side
             thread will be machined regardless of the value specifi ed   Recommended  U  9≤E≤30  6≤U≤E-3  P.90
             for U in  .                                                   E, U = 1mm increments
           & When   or   is specifi ed, the recommended support unit
             may not be available. Please reconfi rm.               E                                  Actuators
           & When specifying any alteration, the nut motion range (Y      No machining of big
             dimension) may become shorter. Please make sure that   steps male thread on the
             the nut motion range is greater than the full length of the   fi xed side                P.99
             nut.                                                          No machining of big steps
                                                          Standard         male thread on the fi xed side
                                                           Change
