P. 35

1
                                                                                 Economy Series
          Product Overview                                                           Ball Screws



          2Short delivery time                                                                       Lead Screws / Actuators  Ball Screws /
          · Drawing-based machining is no longer required, saving the time for drawing
            Generic products                                                 Place      Receive
              in the market           The customer draws by themself        an order   the goods      Ball Screws
            MISUMI Economy  MISUMI draws  Place     Receive
                series                   an order   the goods            Significant time savings
            *Generic products in the market are similar products which was randomly purchased by our company from online or offline markets  P.31

          2Quality Assurance                                                                         Ball Screws  Precision
          ·Even for MISUMI Economy series, the same factory inspection as that of MISUMI standard products is
           carried out to provide users with products that meet the catalog specifications.          P.49

              Shaft end size check  Locking thread check    Pitch projector   Surface roughness check  for Ball Screw  Support Units


                                                                                                     P.61



                                                         One of factors affect the positioning  One of factors affect the runout  Brackets  Motor
                                                                                                     P.69
          2Specifications
          Rolled Ball Screws                           Precision Ball Screws                          Lead Screws
          Accuracy Screw Shaft Lead  Screw shaft length (mm)  Axial Play  Accuracy Screw Shaft Lead  Screw shaft length (mm)  Axial Play
           grade   O.D.  (mm)  min.  max.     (mm)      grade   O.D.  (mm)  min.  max.    (mm)
                08   02     100     400                     08    02             210                 P.71
                     02                                           02    100
                10                  600                     10                   315
                     04                    0.05 or Less           04                    0.008 or Less  Nuts
                     04                                           04                                  Lead Screw
                12   05             800                     12    10             500
                     10     150                                   05    150                          P.83
                     05                                 C5  15    10
                     10                     0.1 or Less           20
                15                  1200
                     16                                           05                                 Support Units   Lead Screw
           C7        20                                     20    10    200      900    0.015 or Less
                     05                                           20
                20   10                    0.15 or Less           05                                 P.86
                     20                                     25    10    300
                     05     200                                   25
                25   10             2000                                                             Stop Plates  Lead Screw
                     25                     0.2 or Less  *Screw shaft length can be specified in 1mm increments.
                     05
                32   10     300                                                                      P.90
                     32


          ·Economy series support unit and Economy series motor bracket are also available.           Actuators
                                  Economy series support unit               Economy series motor bracket (P.69)  P.99
            Square-Standard Type (P.63)  Square-Narrow Pitch Type (P.65)  Round Type (P.67)  Applicable   Applicable
            Support side  Fixed side  Support side  Fixed side  Support side  Fixed side  servo motor  stepper motor









                                                                                                    32
