Economy Series
Photo Microsensors Product Overview

Economy series

Photo Microsensors

High accuracy detection
Free switching between Normally Open (NO) and Normally Closed (NC)

Complete specifications, with NPN, PNP Cable type, Connector type

2 Advantages of MISUMI Economy series groove type sensors
Proximity Sensors · Advantage 1: Power supply reverse connection , output reverse connection , output short circuit 3 circuit
protection circuits as standard

P.579 Generic products in the market * MISUMI Economy series

Photo Microsensors Light ON Indicator (Red + * 2 Output Circuit Diagram DC 4-Wire Type NPN Output
Cable Color

P.589 L Load (Brown +V Load
(Black Output 1 (Note 1
OUT DC Load
Main IC 5~24V Main Circuit Tr1 ZD2 5~24V DC
Contact Probes _ (Control Output Tr2 ZD1 (White Output 2 (Note 1
±10%
Circuit
100mA or Less
(Blue 0V
P.595 Internal Circuit External Connection Example
12 No protection circuit Output short circuit
Sensors / Contact Probes · Advantage 2: Improved tail plug, not easy to come out, vibration resistant structure Output reverse connection
Protection circuit
Powersupplyreverseconnection

Generic products in the market * MISUMI Economy series

No protection measures, easy to loosen With tail plug snap inside, the wire is not easy to loosen
