Page 895 - MiSUMi FA Mechanical Components Economy Series

Slide Rails Three Step Slide Light Load Type (Width:20mm, Steel) With Tap

Rail Length L 300mm, Stroke ST 220mm

Shipping
70.70 MYR from
5 days

For price with different specification, please check our website Handles

Stroke ST P.825
L L
D 20 20 D
C C Hinges
B B
A A
100 100 P.841
15 15

3-П3.2×4 4-M3×2.7 4-M3×2.7 3-П3.2×4 Knobs

2.7 2.7 P.858
M3 M3 rail Linear slide

20 П4 П4
P.876
17
16
.Material: Steel(Q235)
& The cross-sectional shapes may be slightly different due to the production batch. 4Surface Treatment: Zinc Plating Knobs / Slide Rails Handles / Hinges /
How to create a
model Rail Length L Stroke ST A B C D
200 231 145 160
-
250 280 195 210
MISUMI WEB 300 329 - 160 245 260
1.Search this keyword
slide rail 3 step
2.Select Economy series 350 379 210 295 310
Brand
MISUMI
Economy series 400 428 260 345 360
450 477 205 310 395 410
500 526 230 360 445 460
&The rated load (N/2pcs) of this product series can be checked on the web page.
&Use M4 round head screws or small clamping screws for mounting slide rails.
&When it is installed horizontally, the load capacity is reduced to about 25% of the rated value (reference).
How to create Search on MISUMI official website Configure Clear All
a model Step Step Select Brand Brand
1 slide rail 3 step 2 MISUMI MISUMI
Economy Series
Input the keyword and search on the website
Economy series

892
