19
Ultra Low Cross Recessed Flat Head Screws

Nominal Thread M3, Length L 6mm Shims / Flat Keys Screws / Collars /

Thinnest 0.5mm Saving Up to 80 %
vs Standard Type
Shipping
from
21.35 MYR 1 day Screws

Pack 50pcs Included P.911

For price with different specification, please check our website Washers Metal

M×P
P.913

A
To the first starting tooth .Material: Equivalent to SCM435 Metal Collars
E L )Hardness: 32~39HRC
Strength 10.9 P.916
Head Strength 5.8 (Reference Value)
4Surface Treatment: Trivalent Chromate Treatment
How to create a Nominal Thread Length L Selection Thread Diameter A E Shims
model M M × Pitch P
2 3 4 5 6 2×0.4 4 0.5 P.917
MISUMI WEB
1.Search this keyword 2.5 3 4 5 6 2.5×0.45 5 0.6
low head screw
2.Select Economy series 3 5 6 8 10 3×0.5 6 0.8 Parallel Keys
Brand
MISUMI 4 5 6 8 10 12 4×0.7 8 0.9
Economy series P.919
5 6 8 10 12 5×0.8 9 1

How to create Search on MISUMI official website Configure Clear All
a model Step Step Select Brand Brand
1 low head screw 2 MISUMI MISUMI
Economy Series
Input the keyword and search on the website
Economy series
2Usage diff erence with standard product:
.Material Head Shape
MISUMI Economy series SCM435 equivalent Cross recessed fl at head
MISUMI standard product SUS304 equivalent Hexagon Socket
Comparison of Screw Head Shape
Economy series Cross Hole (SCM435) Standard product Hexagon Socket (SUS304)

More thickness Less thickness

Feature 1: More thickness is reserved in the cross hole, and the head is not easy to break
Feature 2: The cross hole can bear with greater breaking torque (cross hole 2.6N·m, hexagon socket 1.3N·m)
* The above data is limited to sample test results, which is for reference only.
* The test data are obtained through testing by our company, which are for reference only
