Economy Series Product Overview
Metal Washers / Metal Collars
Screws / Collars / Shims / Flat Keys YV 6WDQGDUG 7\SH

Economy series 6DYLQJ
8S WR
Screws Metal Washers & ᵖᵎ

Metal Collars
P.911
Metal Washers CNC Machining

Accuracy Assurance
P.913
Metal Collars Popular specifications

Widely Used
P.916

Shims 2 Specification difference between Economy series and MISUMI standard product
· Metal Washer
P.917 Suitable for fixed parts or spacing, etc. with general strength requirements
Parallel Keys Material Equivalent to S45C Low Carbon Free Cutting Steel
MISUMI Economy series
MISUMI standard product
Difference Points
Electroless Nickel Plating
P.919 Surface Treatment Ferroferric Oxide Protective Film or Trivalent Chromate Treatment
D*=16 or Less C0.2 or Less
Chamfer Micro chamfer
D=20 or More C0.5 or Less
· Metal collar
Suitable for fixed parts or adjusting height
Difference Points MISUMI standard product MISUMI Economy series
Material Equivalent to S45C General structural steel or carbon steel
Surface Treatment Ferroferric Oxide Protective Film or Trivalent Chromate Treatment
Electroless Nickel Plating
D*=16 or Less C0.1~C0.2
Chamfer Micro chamfer
D=20 or More C0.5 or Less
*D means outside diameter
2 Example of the main use of washer
· For spring washers Metal Washers · For fixing bearings Metal Washers

Metal Washers

2 Example of the main use of collar
· For spacing adjustment Metal Collars · For height adjustment
or cushioning
Metal
Collars
