2 Setting Parameter Description
Press and hold the MODE key and the left shift key at the same time until Cod( ) is displayed, and
in this state, enter and modify the state of Cod( ) =0020 through and keys.
20
Display Default
Symbol Code Meaning Other Description Range Value
Select K, J, R, S, B, E, N, T, PT,
SN sensor Different input models need to Cu, O.K, 0-50, 0-5V, 1-50 K Heat Insulating Plates Heaters / Temperature Sensors /
input signal match different input resistors.
Unit
Unit °C: Celsius degree; °F: Fahrenheit degree °C, °F °C
selection
Output RLY: Switch relay output Heaters
OUT RLY RLY Cartridge
Method SSR: DC12V output
HOT: Heating control, i.e. reverse control; P.929
COL: Cooling control, i.e. forward control; HOT, COL, H-C
H-C: Simultaneous control of heating and cooling
Control Note: For COL and H-C
Dir HOT
Direction control modes, Sensors Temperature
The output control of both HOT and COL modes is OUT1 only RLY mode is
H-C mode OUT1 is heating control output applicable.
OUT2 is cooling control output P.937
Number of
Tt temperatures Make the display temperature close 0-10 6 Controllers Temperature
tracked to the set value within the range of the set value ±Tt
0: Manual control prohibited: P.949
Whether 1: Manual control allowed
manual When the manual control is allowed, the shift key can be
Hnd used to enter and exit the manual control state, 0,1 0
control is Plates Heat Insulating
allowed and or key can be used to control
the output power percentage of the instrument in the
manual control state.
P.953
Over 0-Turn off the function
temperature Other value, when exceeding the setting value.
FAC 0-100 0
display The excess part is displayed in proportion, with the
limit displayed value = SV+ (PV-SV)/FAC
COD = 0040 Access to factory parameters 4
1 CTON = 1000 Allowed to directly modify the SU value through the plus or minus key, and SU is not displayed in the upper row
= 0001 With CT function
2 TON = 0000 Alarm 1 is an excitation alarm
0001 Alarm 1 is an non-excitation alarm
= 0000 Alarm 2 is an excitation alarm
0 010 Alarm 2 is an non-excitation alarm
= 1000 With ET timing function
3 CON = 0001 Allowed to manually turn on and turn off the output, and enter the closed output state when powered on
Tap the shift key to turn on the output
0100 With the communication function
1000 Allowed to turn on the adaptive function

COD = 0060 Access to factory parameters 5
1 LBAT Output fault monitoring time
2 LBAB Output fault monitoring width
LBAT Heating output monitoring time, in seconds.
LBAB Heating output monitoring width, in the same unit as PV value.
A heating fault is indicated when the PV measured temperature change is less than LBAB after a full-cycle heating output or a
full-cycle shutdown output with a duration of LBAT time, and no heating fault is indicated if the change is greater than LBAB.
SV = EER1 Indicate heating failure.
3 RLRS Solid state and relay selection output
SrrL Select whether the heating type is relay or solid-state signal output
=0 Relay heating = 1 Solid-state heating
COD = 1168 Restore factory settings
