Economy Series
Temperature Controllers Product Overview

YV 6WDQGDUG 7\SH
Economy series 6DYLQJ
20 Temperature Controllers 8S WR
Heaters / Temperature Sensors / Heat Insulating Plates Relay output/SSR drive output free switchingtching ᵕᵓ

Easy connection to PLC with RS485 communication function
Cartridge Heaters Can be installed in the control cabinet for use

P.929 Adopting terminal block wiring structure
Temperature Sensors

2 Name of Each Part
P.937 2 External Dimension and Opening Dimension 2 Function Description of Control Panel
C-MTCTRST
C-MTCTRS
Temperature Controllers Current Value (PV) Display (Red)
(with RS485 communication)
The current measured value (PV) is
displayed in the operation mode,
and the internal parameter name is

Setting Value (SV) Display (Green)
P.949 displayed in the setup mode.
The setting value of the control target
Heat Insulating Plates Appearance COM/ F mode, and the current setting value
(SV) is displayed in the operation
of that parameter is displayed in the
setup mode.
— Self-tuning Indicator: When performing self-tuning, the AT light flashes
P.953 Control/Alarm Output Indicator
in a cycle of 1 second.
* When SSR controls the cycle/phase control of the drive output mode,
the light is on when the operation amount exceeds 3.0%.
— AL1/AL2: The light is on when Alarm1 and Alarm2 alarm output is ON.
External Size 48mm×48mm 48mm×96mm OUT: The light is on when the control output (Main Control Output) is ON.
Key: Used to enter the parameter group setting, return to the
Housing Size 45mm×45mm×75mm operation mode, switch the parameter group, and save the setting value.
L × W × H 45mm×92mm×75mm Direction Key: Used to enter the setting value change mode or move
Mounting Size 45mm×45mm 45mm×92mm the digit to change the value up/down.
Function Key: Pressing key and key simultaneously for 3 seconds will
activate the [DI-K] digital
input key function (run/stop, alarm clear, self-tuning) setting.
Temperature Unit Indicator (°C/°F) : Displays the current temperature unit.
2 Comparison with generic products in the market
2 Comparison of anti-disturbance performance 2 First overshoot comparison
Generic products in the market MISUMI Economy series products Generic products in the market MISUMI Economy series products
Large hunting and long time to reach Small hunting and short time to reach MISUMI Economy series
and stabilize the set temperature and stabilize the set temperature Traditional PID control intelligent PID control
Temperature Temperature
+3 +3
t1 t2
Temperature Temperature
Time Time
-3 -3
Temperature Temperature
Set Temperature Set Temperature
Current Temperature Current Temperature
Time Time
Set Temperature Set Temperature
Generic products in the market MISUMI Economy series
Current Temperature Current Temperature temperature control instrument
Time Time
949 * Generic products in the market are similar products randomly purchased by our company from online or offline markets
