iglidur  G                                                                                                                                                                                                              iglidur  G
                                                                                                                                                                                                                                      ®
             ®
         +130°C                                                                                                                                                                                                                   +130°C
          80MPa                                                                                                                                                                                                                   80MPa
                      Bearing technology | Plain bearings | iglidur  G                                                              Product range
                                                                                                    ®
          Thrust washer (form T)                                                                                                    d1             d2          d4         d5          h         d6         Øs      Part No.
                                                                             d1
                                                                                                                                    +0.25          -0.25      -0.12     +0.375     +0.2/-0.2   +0.12       -0.05
                                                                                                                                                              +0.12     +0.125
                                                                     s
                                                                             d2                                                     [mm]           [mm]       [mm]       [mm]       [mm]       [mm]        [mm]
                                                                                                                                    14             20          4)          4)         1         20         1.5     GTM-1420-015
                                                                                                                                    14             26          20         2           1         26         1.5     GTM-1426-015
                                                                                                                                    15             19          4)          4)        0.5        19         0.8     GTM-1519-008
                                                                                                                                    15             22          4)          4)        0.5        22         0.8     GTM-1522-008
                                                                                       d5
                                                                                                                                    15             24         19.5        1.5         1         24         1.5     GTM-1524-015
                                                                                    d4
                                                                                                                                    15             24          4)          4)         2         24         2.75    GTM-1524-0275
                                                                                                                                    16             28          4)          4)        0.7        28          1      GTM-1628-010
                                                                             d6
                                                                                                                                    16             30          22         2           1         30         1.5     GTM-1630-015
                                                                                        h
               Dimensions according to ISO 3547-1 and                                                                               18             32          25         2           1         32         1.5     GTM-1832-015
               special dimensions                                                                                                   20             36          28         3           1         36         1.5     GTM-2036-015
                                                                                                                                    22             30          4)          4)         1         30         1.5     GTM-2230-015
               Order example: GTM-0408-005 – no minimum order quantity.                                                             22             38          30         3           1         38         1.5     GTM-2238-015
               G iglidur  material T Thrust washer M Metric 04 Inner Ø d1 08 Outer Ø d2 005 Height s                                24             42          33         3           1         42         1.5     GTM-2442-015
                      ®
                                                                                                                                    26             44          35         3           1         44         1.5     GTM-2644-015
                                                                                                                                    28             48          38         4           1         48         1.5     GTM-2848-015
           d1            d2          d4         d5          h         d6          Øs     Part No.                                   28.5           35.8        4)          4)        0.2       35.8        0.5     GTM-2835-005
           +0.25         -0.25      -0.12     +0.375     +0.2/-0.2   +0.12       -0.05                                              32             45.8        4)          4)        0.7       45.8         1      GTM-3246-010
                                    +0.12     +0.125                                                                                32             54          43         4           1         54         1.5     GTM-3254-015
           [mm]          [mm]       [mm]       [mm]       [mm]        [mm]       [mm]                                               38             62          50         4           1         62         1.5     GTM-3862-015
           4              8          4)          4)        0.2         8         0.5     GTM-0408-005                               40             60          4)          4)         4)        60         3.5     GTM-4060-035
           4              9          4)          4)        0.3         9         0.6     GTM-0409-006                               42             66          54         4           1         66         1.5     GTM-4266-015
           4              9          4)          4)        0.3         9         1.6     GTM-0409-016                               48             60          4)          4)        1.5        74          2      GTM-4860-020
           4              10         4)          4)        0.2        10         0.5     GTM-0410-005                               48             74          61         4          1.5        74          2      GTM-4874-020
           4              11         4)          4)        0.2        11         0.5     GTM-0411-005                               52             78          65         4          1.5        78          2      GTM-5278-020
           5             9.5         4)          4)        0.3        9.5        0.6     GTM-0509-006                               52.5           69          4)          4)        1.5        69          2      GTM-52569-020
           6              12         4)          4)         1         12         1.5     GTM-0612-015                               62             78          4)          4)        1.5        78          2      GTM-6278-020
           6              15         4)          4)         1         15         1.5     GTM-0615-015                               62             90          4)          4)        0.7        90          1      GTM-6290-010
           6              20         13         1.5         1         20         1.5     GTM-0620-015                               62             90          76         4          1.5        90          2      GTM-6290-020
           6.2            11         4)          4)        0.7        11          1      GTM-0611-010                               68             81          4)          4)        1.5        81          2      GTM-6881-020
           7              12         4)          4)        0.2        12         0.5     GTM-0712-005                               78             114         4)          4)         1         114        1.5     GTM-78114-015
           7              13         4)          4)        0.2        13         0.5     GTM-0713-005                               80.5           114         4)          4)         1         114        1.5     GTM-80114-015
           8              15         4)          4)        0.2        15         0.5     GTM-0815-005                               4)  Design without fixing hole
           8              15         4)          4)         1         15         1.5     GTM-0815-015
           8              18         4)          4)        0.7        18          1      GTM-0818-010
           8              18         13         1.5         1         18         1.5     GTM-0818-015
           8              18         4)          4)        1.5        18          2      GTM-0818-020
           9              13         4)          4)        0.7        13          1      GTM-0913-010                                    Available from stock                               Ordering note
           9              18        13.5        1.5         1         18         1.5     GTM-0918-015                                    Detailed information about delivery time online.   Our prices are scaled according to order
           10            17.8        4)          4)        0.2        17.8       0.5     GTM-1018-005                                    www.igus-asean.com/24                              quantities, current prices can be found online.
           10             18         4)          4)        0.7        18          1      GTM-1018-010                                    Order online
           10             18         4)          4)         1         18         1.5     GTM-1018-015                                    including delivery times, prices, online tools      Discount scaling
           10             18         4)          4)        1.5        18          2      GTM-1018-020                                    www.igus-asean.com/G                                1-9           50-99         500-999
           10             20         4)          4)        0.7        20         1.5     GTM-1020-015                                                                                        10-24         100-199       1,000-2,499
           11             15         4)          4)        0.7        15          1      GTM-1115-010                                                                                        25-49         200-499       2,500-4,999
           11             27         4)          4)        0.2        27         0.5     GTM-1127-005                                                                                       No minimum order value.
           12             24         18         1.5         1         24         1.5     GTM-1224-015                                                                                       No low-quantity surcharges.
           12             30         4)          4)         1         30         1.5     GTM-1230-015                                                                                       Free shipping within Germany for orders

          4)  Design without fixing hole                                                                         ASEAN 09/2023   ASEAN 09/2023                                              above €150.
