Page 98 - IGUS Bearing

iglidur G iglidur G
®
®
+130°C +130°C
80MPa 80MPa
Bearing technology | Plain bearings | iglidur G Product range
®
d1 d1 d2 d3 b1 b2 Part No. d1 d1 d2 d3 b1 b2 Part No. d1 d1 d2 d3 b1 b2 Part No. d1 d1 d2 d3 b1 b2 Part No.
Tolerance 3) d13 3) h13 h13 Tolerance 3) d13 3) h13 h13 Tolerance 3) d13 3) h13 h13 Tolerance 3) d13 3) h13 h13
[mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm]
16.0 18.0 24.0 9.0 1.00 GFM-1618-09 28.0 30.0 36.0 31.0 1.00 GFM-283036-31 60.0 65.0 80.0 62.0 2.00 GFM-606580-62 100.0 105.0 113.0 100.0 2.50 GFM-100105-100
16.0 18.0 24.0 12.0 1.00 GFM-1618-12 28.0 30.0 35.0 36.0 1.00 GFM-2830-36 65.0 70.0 78.0 50.0 2.00 GFM-6570-50 110.0 +0.072 115.0 123.0 100.0 2.50 GFM-110115-100
16.0 18.0 24.0 16.0 1.00 GFM-1618-16 28.0 30.0 35.0 48.0 1.00 GFM-2830-48 70.0 +0.060 75.0 83.0 50.0 2.00 GFM-7075-50 120.0 +0.212 125.0 133.0 80.0 2.50 GFM-120125-80
16.0 18.0 24.0 17.0 1.00 GFM-1618-17 28.0 32.0 39.0 20.0 2.00 GFM-283239-20 70.0 +0.180 75.0 83.0 85.5 2.00 GFM-7075-855 120.0 125.0 133.0 100.0 2.50 GFM-120125-100
16.0 18.0 24.0 21.0 1.00 GFM-1618-21 28.0 32.0 50.0 35.0 2.00 GFM-283250-35 75.0 80.0 88.0 50.0 2.00 GFM-7580-50 125.0 130.0 138.0 100.0 2.50 GFM-125130-100
17.0 19.0 25.0 9.0 1.00 GFM-1719-09 30.0 31.0 36.0 20.0 0.50 GFM-3031-20 80.0 85.0 93.0 50.0 2.50 GFM-8085-50 130.0 +0.085 135.0 143.0 100.0 2.50 GFM-130135-100
17.0 19.0 25.0 16.0 1.00 GFM-1719-16 30.0 31.0 35.0 30.0 0.50 GFM-3031-30 80.0 85.0 93.0 100.0 2.50 GFM-8085-100 140.0 +0.245 145.0 153.0 100.0 2.50 GFM-140145-100
17.0 19.0 25.0 25.0 1.00 GFM-1719-25 30.0 +0.040 32.0 37.0 4.0 1.00 GFM-3032-04 85.0 90.0 98.0 100.0 2.50 GFM-8590-100 150.0 155.0 163.0 40.0 2.50 GFM-150155-40
18.0 +0.032 20.0 26.0 4.0 1.00 GFM-1820-04 30.0 +0.124 32.0 37.0 12.0 1.00 GFM-3032-12 90.0 +0.072 95.0 103.0 100.0 2.50 GFM-9095-100 150.0 155.0 163.0 100.0 2.50 GFM-150155-100
18.0 +0.102 20.0 26.0 6.0 1.00 GFM-1820-06 30.0 32.0 37.0 17.5 1.00 GFM-3032-17 95.0 +0.212 100.0 108.0 100.0 2.50 GFM-95100-100 195.0 +0.100 205.0 240.0 65.0 5.00 GFM-195205240-
18.0 20.0 22.0 6.0 1.00 GFM-182022-06 30.0 32.0 37.0 22.0 1.00 GFM-3032-22 100.0 105.0 113.0 42.5 2.50 GFM-100105-425 +0.285 65
18.0 20.0 26.0 9.0 1.00 GFM-1820-09 30.0 34.0 42.0 9.0 2.00 GFM-3034-09 3) After press-fit. Testing methods, page 61
18.0 20.0 26.0 11.0 1.00 GFM-1820-11 30.0 34.0 40.0 10.0 2.00 GFM-303440-10
18.0 20.0 26.0 12.0 1.00 GFM-1820-12 30.0 34.0 42.0 16.0 2.00 GFM-3034-16
18.0 20.0 26.0 17.0 1.00 GFM-1820-17 30.0 34.0 42.0 20.0 2.00 GFM-3034-20
18.0 20.0 26.0 22.0 1.00 GFM-1820-22 30.0 34.0 42.0 26.0 2.00 GFM-3034-26
18.0 20.0 26.0 30.0 1.00 GFM-1820-30 30.0 34.0 42.0 37.0 2.00 GFM-3034-37
18.0 20.0 26.0 32.0 1.00 GFM-1820-32 32.0 36.0 40.0 16.0 2.00 GFM-3236-16
18.0 22.0 26.0 28.0 2.00 GFM-1822-28 32.0 36.0 40.0 26.0 2.00 GFM-3236-26
20.0 +0.020 21.0 26.0 3.5 0.50 GFM-2021-035 34.0 38.0 50.0 35.0 2.00 GFM-343850-35
20.0 +0.072 21.0 25.0 15.0 0.50 GFM-2021-15 35.0 39.0 47.0 5.8 2.00 GFM-3539-058
20.0 21.0 25.0 20.0 0.50 GFM-2021-20 35.0 39.0 47.0 7.0 2.00 GFM-3539-07
20.0 23.0 30.0 7.0 1.50 GFM-2023-07 35.0 39.0 47.0 12.0 2.00 GFM-3539-12
20.0 23.0 26.0 7.0 1.50 GFM-202326-07 35.0 39.0 47.0 16.0 2.00 GFM-3539-16
20.0 23.0 30.0 11.5 1.50 GFM-2023-11 35.0 39.0 47.0 26.0 2.00 GFM-3539-26
20.0 23.0 28.0 15.0 1.50 GFM-202328-15 35.0 39.0 47.0 36.0 2.00 GFM-3539-36
20.0 23.0 30.0 16.5 1.50 GFM-2023-16 38.0 42.0 54.0 10.0 2.00 GFM-3842-10
20.0 23.0 29.0 20.0 1.50 GFM-202329-20 38.0 42.0 54.0 22.0 2.00 GFM-3842-22
20.0 +0.040 23.0 30.0 21.5 1.50 GFM-2023-21 40.0 44.0 52.0 7.0 2.00 GFM-4044-07
20.0 +0.124 23.0 26.0 21.5 1.50 GFM-202326-21 40.0 +0.050 44.0 52.0 14.0 2.00 GFM-4044-14
22.0 24.0 30.0 25.0 1.00 GFM-2224-25 40.0 +0.150 44.0 52.0 20.0 2.00 GFM-4044-20
22.0 25.0 29.0 4.5 1.50 GFM-222529-045 40.0 44.0 52.0 30.0 2.00 GFM-4044-30
22.0 25.0 30.0 21.5 1.50 GFM-222530-215 40.0 44.0 52.0 40.0 2.00 GFM-4044-40
22.0 25.0 30.0 25.0 1.50 GFM-222530-25 40.0 44.0 52.0 50.0 2.00 GFM-4044-50
22.0 25.0 35.0 31.5 1.50 GFM-222535-315 40.0 46.0 50.0 20.0 2.00 GFM-4046-20
24.0 27.0 32.0 7.0 1.50 GFM-2427-07 42.0 46.0 53.0 19.0 2.00 GFM-4246-19
24.0 27.0 32.0 10.5 1.50 GFM-2427-10 45.0 50.0 58.0 25.0 2.00 GFM-4550-25
+0.020 45.0 50.0 58.0 30.0 2.00 GFM-4550-30 Available from stock Ordering note
25.0 26.0 30.0 25.0 0.50 GFM-2526-25 Detailed information about delivery time online. Our prices are scaled according to order
+0.072 45.0 50.0 58.0 50.0 2.00 GFM-4550-50
25.0 27.0 32.0 7.0 1.00 GFM-2527-07 50.0 55.0 63.0 7.0 2.00 GFM-5055-07 www.igus-asean.com/24 quantities, current prices can be found online.
25.0 27.0 32.0 48.0 1.00 GFM-2527-48 50.0 55.0 63.0 10.0 2.00 GFM-5055-10 Order online
25.0 28.0 30.0 10.0 1.50 GFM-252830-10 50.0 55.0 63.0 25.0 2.00 GFM-5055-25 including delivery times, prices, online tools Discount scaling
25.0 +0.040 28.0 35.0 11.5 1.50 GFM-2528-11 50.0 55.0 63.0 40.0 2.00 GFM-5055-40 www.igus-asean.com/G 1-9 50-99 500-999
25.0 +0.124 28.0 35.0 16.5 1.50 GFM-2528-16 50.0 55.0 63.0 50.0 2.00 GFM-5055-50 10-24 100-199 1,000-2,499
25.0 28.0 35.0 21.5 1.50 GFM-2528-21 60.0 65.0 73.0 7.0 2.00 GFM-6065-07 25-49 200-499 2,500-4,999
26.0 30.0 37.0 12.0 2.00 GFM-2630-12 60.0 +0.060 65.0 73.0 22.0 2.00 GFM-6065-22 No minimum order value.
27.0 30.0 38.0 20.0 1.50 GFM-2730-20 60.0 +0.180 65.0 73.0 30.0 2.00 GFM-6065-30 No low-quantity surcharges.
28.0 30.0 35.0 10.0 1.00 GFM-2830-10 60.0 65.0 73.0 50.0 2.00 GFM-6065-50 Free shipping within Germany for orders

3) After press-fit. Testing methods, page 61 ASEAN 09/2023 ASEAN 09/2023 above €150.
