Page 93 - IGUS Bearing
P. 93

iglidur  G                                                                                                                                                                                                              iglidur  G
                                                                                                                                                                                                                                      ®
             ®
         +130°C                                                                                                                                                                                                                   +130°C
          80MPa                                                                                                                                                                                                                   80MPa
                      Bearing technology | Plain bearings | iglidur  G                                                              Product range
                                                                                                    ®
          Sleeve bearings (form S)                                                                                                  d1         d1      d2     b1   Part No.             d1        d1       d2    b1   Part No.

                                                                                                                                            Tolerance 3)      h13                              Tolerance 3)      h13
                                                                              f1  30°
                                                                                                                                    [mm]               [mm]  [mm]                       [mm]              [mm]  [mm]
                                                                                                                                             +0.040                                     13.0              15.0   7.0  GSM-1315-070
                                                                                                                                    8.0                12.0   9.0  GSM-0812-09
                                                                                                                                                                                                                 7.5
                                                                d1  0.5           d2                                                9.0      +0.130    10.0  12.0  GSM-0910-12          13.0              15.0  10.0  GSM-1315-075
                                                                                                                                                                                                                      GSM-1315-10
                                                                                                                                             +0.013
                                                                                                                                                                                                          15.0
                                                                                                                                                                                        13.0
                                                                                                                                    9.0      +0.049    10.0  16.0  GSM-0910-16          13.0              15.0  15.0  GSM-1315-15
                                                                 30°
                                                                         b1                                                         9.0      +0.025    11.0   6.0  GSM-0911-06          13.0              15.0  20.0  GSM-1315-20
                                                                                                                                    9.0      +0.083    11.0  20.0  GSM-0911-20          13.0              15.0  25.0  GSM-1315-25
                                                                                                                                    10.0               11.0   6.0  GSM-1011-06          14.0    +0.032    16.0   3.0  GSM-1416-03
                                                                                                                                    10.0               11.0   7.0  GSM-1011-07          14.0              16.0   6.0  GSM-1416-06
                                                             2)  Thickness < 0.6mm: chamfer = 20°                                                                                               +0.102
          Chamfer in relation to d1                                                                                                 10.0     +0.013    11.0  10.0  GSM-1011-10          14.0              16.0   8.0  GSM-1416-08
          d1 [mm]   Ø 1-6     Ø 6-12   Ø 12-30    Ø > 30           Dimensions according to ISO 3547-1 and                           10.0     +0.049    11.0  20.0  GSM-1011-20          14.0              16.0  10.0  GSM-1416-10
          f1 [mm]    0.3       0.5        0.8       1.2            special dimensions                                               10.0               11.0  25.0  GSM-1011-25          14.0              16.0  12.0  GSM-1416-12
                                                                                                                                    10.0               11.0  30.0  GSM-1011-30          14.0              16.0  15.0  GSM-1416-15
               Order example: GSM-0103-02 – no minimum order quantity.                                                              10.0               12.0   4.0  GSM-1012-04          14.0              16.0  20.0  GSM-1416-20
               G iglidur  material S Cylindrical M Metric 01 Inner Ø d1 03 Outer Ø d2 02 Total length b1                            10.0               12.0   4.5  GSM-1012-045         14.0              16.0  25.0  GSM-1416-25
                      ®
                                                                                                                                     10.0              12.0   5.0  GSM-1012-05          14.0              16.0  45.0  GSM-1416-45
                                                                                                                                     10.0              12.0   6.0  GSM-1012-06          15.0    +0.016    16.0  10.0  GSM-1516-10
           d1        d1       d2    b1   Part No.             d1        d1       d2    b1   Part No.                                 10.0              12.0   7.0  GSM-1012-07          15.0    +0.059    16.0  15.0  GSM-1516-15
                  Tolerance 3)      h13                              Tolerance 3)      h13                                           10.0              12.0   8.0  GSM-1012-08          15.0              17.0   4.0  GSM-1517-04
           [mm]              [mm]  [mm]                       [mm]              [mm]  [mm]                                           10.0    +0.025    12.0   9.0  GSM-1012-09          15.0              17.0  10.0  GSM-1517-10
           1.5               3.0    2.0  GSM-0103-02          6.0                8.0   8.0  GSM-0608-08                              10.0    +0.083    12.0  10.0  GSM-1012-10          15.0              17.0  12.0  GSM-1517-12
           2.0               3.5    3.0  GSM-0203-03          6.0     +0.020     8.0   9.5  GSM-0608-09                              10.0              12.0  12.0  GSM-1012-12          15.0              17.0  15.0  GSM-1517-15
           2.5     +0.014    4.5    5.0  GSM-02504-05         6.0     +0.068     8.0  10.0  GSM-0608-10                              10.0              12.0  14.0  GSM-1012-14          15.0              17.0  20.0  GSM-1517-20
           3.0     +0.054    4.5    3.0  GSM-0304-03          6.0                8.0  11.8  GSM-0608-11                              10.0              12.0  15.0  GSM-1012-15          15.0              17.0  25.0  GSM-1517-25
           3.0               4.5    5.0  GSM-0304-05          6.0                8.0  13.8  GSM-0608-13                              10.0              12.0  17.0  GSM-1012-17          16.0              18.0   5.5  GSM-1618-055
           3.0               4.5    6.0  GSM-0304-06          7.0     +0.013     8.0  10.0  GSM-0708-10                              10.0              12.0  20.0  GSM-1012-20          16.0              18.0   8.0  GSM-1618-08
           4.0               5.5    4.0  GSM-0405-04          7.0     +0.049     8.0  19.0  GSM-0708-19                              10.0              13.0  13.5  GSM-1013-13          16.0    +0.032    18.0  10.0  GSM-1618-10
           4.0     +0.020    5.5    6.0  GSM-0405-06          7.0                9.0   8.0  GSM-0709-08                              10.0    +0.025    14.0  10.0  GSM-1014-10          16.0    +0.102    18.0  12.0  GSM-1618-12
           4.0     +0.068    7.0    5.5  GSM-0407-05          7.0     +0.025     9.0   9.0  GSM-0709-09                              10.0    +0.115    14.0  20.0  GSM-1014-20          16.0              18.0  13.5  GSM-1618-13.5
           4.5               6.0    8.0  GSM-0406-08          7.0     +0.083     9.0  10.0  GSM-0709-10                              10.0    +0.040    16.0  10.0  GSM-1016-10          16.0              18.0  15.0  GSM-1618-15
           5.0     +0.010    6.0    4.6  GSM-0506-046         7.0                9.0  12.0  GSM-0709-12                                      +0.130                                     16.0              18.0  20.0  GSM-1618-20
           5.0     +0.040    6.0    5.0  GSM-0506-05          8.0                9.0   5.0  GSM-0809-05                              12.0              13.0   4.7  GSM-1213-047         16.0              18.0  25.0  GSM-1618-25
           5.0               6.0    7.0  GSM-0506-07          8.0     +0.013     9.0   6.0  GSM-0809-06                              12.0    +0.016    13.0  10.0  GSM-1213-10          16.0              18.0  30.0  GSM-1618-30
           5.0               7.0    5.0  GSM-0507-05          8.0     +0.049     9.0   8.0  GSM-0809-08                              12.0    +0.059    13.0  12.0  GSM-1213-12          16.0              18.0  38.5  GSM-1618-38.5
           5.0     +0.020    7.0    7.0  GSM-0507-07          8.0                9.0  12.0  GSM-0809-12                              12.0              13.0  15.0  GSM-1213-15          16.0              18.0  50.0  GSM-1618-50
           5.0     +0.068    7.0    8.0  GSM-0507-08          8.0               10.0   5.0  GSM-0810-05                              12.0              14.0   4.0  GSM-1214-04          17.0              19.0  15.0  GSM-1719-15
           5.0               7.0   10.0  GSM-0507-10          8.0               10.0   6.0  GSM-0810-06                              12.0              14.0   5.0  GSM-1214-05          18.0    +0.016    19.0  15.0  GSM-1819-15
           6.0               7.0    6.0  GSM-0607-06          8.0               10.0   6.8  GSM-0810-07                              12.0              14.0   6.0  GSM-1214-06                  +0.059
           6.0     +0.010    7.0   12.0  GSM-0607-12          8.0               10.0   8.0  GSM-0810-08                              12.0              14.0   8.0  GSM-1214-08          18.0              20.0   6.0  GSM-1820-06
           6.0     +0.040    7.0   17.0  GSM-0607-17          8.0               10.0  10.0  GSM-0810-10                              12.0              14.0  10.0  GSM-1214-10          18.0              20.0  10.0  GSM-1820-10
           6.0               7.0   17.5  GSM-0607-17.5        8.0               10.0  12.0  GSM-0810-12                              12.0    +0.032    14.0  12.0  GSM-1214-12          18.0              20.0  12.0  GSM-1820-12
           6.0               7.0   19.0  GSM-0607-19          8.0     +0.025    10.0  13.8  GSM-0810-13                              12.0    +0.102    14.0  14.0  GSM-1214-14          18.0              20.0  15.0  GSM-1820-15
           6.0               8.0    1.5  GSM-0608-015         8.0     +0.083    10.0  14.0  GSM-0810-14                              12.0              14.0  15.0  GSM-1214-15          18.0    +0.032    20.0  20.0  GSM-1820-20
           6.0               8.0    2.5  GSM-0608-025         8.0               10.0  15.0  GSM-0810-15                              12.0              14.0  20.0  GSM-1214-20          18.0    +0.102    20.0  25.0  GSM-1820-25
           6.0     +0.020    8.0    3.0  GSM-0608-03          8.0               10.0  16.0  GSM-0810-16                              12.0              14.0  25.0  GSM-1214-25          18.0              20.0  34.0  GSM-1820-34
           6.0     +0.068    8.0    4.0  GSM-0608-04          8.0               10.0   18.0  GSM-0810-18                             12.0              15.0   6.0  GSM-1215-06          18.0              20.0  38.0  GSM-1820-38
           6.0               8.0    5.0  GSM-0608-05          8.0               10.0   20.0  GSM-0810-20                             12.0              15.0  22.0  GSM-1215-22          18.0              20.0  45.0  GSM-1820-45
           6.0               8.0    5.5  GSM-0608-055         8.0               10.0   22.0  GSM-0810-22                             12.0    +0.050    16.0  10.0  GSM-1216-10          18.0              22.0  30.0  GSM-1822-30
           6.0               8.0    6.0  GSM-0608-06          8.0               10.0   25.0  GSM-0810-25                             12.0    +0.160    16.0  20.0  GSM-1216-20

          3)  After press-fit. Testing methods, page 61                                                          ASEAN 09/2023   ASEAN 09/2023  3)  After press-fit. Testing methods, page 61
          90    3D-CAD, finder and service life calculation ... www.igus-asean.com/G                                                                            Lubrication-free made easy ... from stock ... no minimum order quantity  91
