iglidur Imperial product range | iglidur | Flanged bearings Imperial product range | iglidur | Flanged bearings iglidur
®
®
form F form F
d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No. d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No.
h13 max. min. max. min. max. min. h13 max. min. max. min. max. min.
1 3/4 1 15/16 2 2.3750 .0930 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 A181FI-2831-32 1/2 19/32 1/2 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A350FI-0809-08
2 2 3/16 2 2.6250 .0930 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 A181FI-3235-32 1/2 19/32 3/4 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A350FI-0809-12
1/2 19/32 1 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A350FI-0809-16
iglidur A200 Chapter Page 433 5/8 23/32 1/2 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 A350FI-1011-08
®
5/8 23/32 3/4 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 A350FI-1011-12
d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No. 5/8 23/32 1 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 A350FI-1011-16
h13 max. min. max. min. max. min. 3/4 7/8 1/2 1.1250 .0620 .7532 .7499 .8755 .8747 .7491 .7479 A350FI-1214-08
1/8 1/4 1/4 .3600 .0470 .1280 .1262 .2515 .2510 .1250 .1241 AFI-0204-04 3/4 7/8 3/4 1.1250 .0620 .7532 .7499 .8755 .8747 .7491 .7479 A350FI-1214-12
3/16 5/16 1/4 .3700 .0470 .1905 .1887 .3140 .3135 .1875 .1866 AFI-0305-04 3/4 7/8 1 1.1250 .0620 .7532 .7499 .8755 .8747 .7491 .7479 A350FI-1214-16
1/4 3/8 1/4 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 AFI-0406-04 7/8 1 1/2 1.2500 .0620 .8782 .8749 1.0005 .9997 .8741 .8729 A350FI-1416-08
1/4 3/8 3/8 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 AFI-0406-06 7/8 1 3/4 1.2500 .0620 .8782 .8749 1.0005 .9997 .8741 .8729 A350FI-1416-12
5/16 7/16 1/2 .5600 .0620 .3164 .3141 .4390 .4385 .3125 .3116 AFI-0507-08 7/8 1 1 1.2500 .0620 .8782 .8749 1.0005 .9997 .8741 .8729 A350FI-1416-16
3/8 1/2 1/4 .6250 .0620 .3164 .3141 .4390 .4385 .3125 .3116 AFI-0608-04 1 1 1/8 1/2 1.3750 .0620 1.0032 .9999 1.1255 1.1247 .9991 .9979 A350FI-1618-08
3/8 1/2 1/2 .6250 .0620 .3789 .3766 .5015 .5010 .3750 .3741 AFI-0608-08 1 1 1/8 3/4 1.3750 .0620 1.0032 .9999 1.1255 1.1247 .9991 .9979 A350FI-1618-12
1/2 5/8 1/2 .8750 .0620 .5047 .5020 .6257 .6250 .5000 .4983 AFI-0810-08 1 1 1/8 1 1.3750 .0620 1.0032 .9999 1.1255 1.1247 .9991 .9979 A350FI-1618-16
1/2 5/8 3/4 .8750 .0620 .5047 .5020 .6257 .6250 .5000 .4983 AFI-0810-12 1 1/4 1 13/32 1 1.6870 .0780 1.2537 1.2498 1.4068 1.4058 1.2488 1.2472 A350FI-2022-16
5/8 13/16 1 1.0630 .1560 .6297 .6270 .8135 .8125 .6250 .6240 AFI-1013-16 1 1/4 1 13/32 1 1/4 1.6870 .0780 1.2537 1.2498 1.4068 1.4058 1.2488 1.2472 A350FI-2022-20
3/4 1 3/4 1.2500 .1560 .7559 .7525 1.0010 1.0000 .7500 .7490 AFI-1216-12 1 1/2 1 21/32 1 2.0000 .0780 1.5037 1.4998 1.6568 1.6558 1.4988 1.4972 A350FI-2426-16
3/4 1 1 1.2500 .1560 .7559 .7525 1.0010 1.0000 .7500 .7490 AFI-1216-16 1 1/2 1 21/32 1 1/2 2.0000 .0780 1.5037 1.4998 1.6568 1.6558 1.4988 1.4972 A350FI-2426-24
7/8 1 1/8 1 1/2 1.3750 .1560 .8809 .8775 1.1260 1.1250 .8750 .8740 AFI-1418-24 1 3/4 1 15/16 2 2.3750 .0930 1.7536 1.7497 1.9381 1.9371 1.7487 1.7471 A350FI-2831-32
1 1 9/32 1 1.5000 .1880 1.0059 1.0025 1.2510 1.2500 1.0000 .9990 AFI-1620-16 2 2 3/16 2 2.6250 .0930 2.0040 1.9993 2.1883 2.1871 1.9981 1.9969 A350FI-3235-32
1 1 9/32 1 1/2 1.5000 .1880 1.0059 1.0025 1.2510 1.2500 1.0000 .9990 AFI-1620-24
1 1/4 1 17/32 1 1.7500 .2000 1.2600 1.2531 1.5005 1.4995 1.2500 1.2490 AFI-2024-16 iglidur A500 Chapter Page 417
®
1 1/4 1 17/32 1 1/2 1.7500 .2000 1.2600 1.2531 1.5005 1.4995 1.2500 1.2490 AFI-2024-24
1 1/2 1 3/4 1 2.0000 .1250 1.5100 1.5032 1.7505 1.7495 1.5000 1.4990 AFI-2428-16 d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No.
1 1/2 1 3/4 1 1/2 2.0000 .1250 1.5100 1.5032 1.7505 1.7495 1.5000 1.4990 AFI-2428-24 h13 max. min. max. min. max. min.
1 3/4 2 1 2.2500 .1250 1.7560 1.7532 2.0005 1.9995 1.7500 1.7490 AFI-2832-16 1/8 3/16 3/16 .3120 .0320 .1266 .1247 .1878 .1873 .1243 .1236 A500FI-0203-03
3/16 1/4 1/4 .3750 .0320 .1888 .1869 .2503 .2497 .1865 .1858 A500FI-0304-04
iglidur A350 Chapter Page 409 1/4 5/16 3/8 .5000 .0320 .2518 .2495 .3128 .3122 .2490 .2481 A500FI-0405-06
®
1/4 5/16 1/2 .5000 .0320 .2518 .2495 .3128 .3122 .2490 .2481 A500FI-0405-08
d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No. 5/16 3/8 1/4 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 A500FI-0506-04
h13 max. min. max. min. max. min. 5/16 3/8 3/8 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 A500FI-0506-06
1/8 3/16 3/16 .3120 .0320 .1266 .1247 .1878 .1873 .1243 .1236 A350FI-0203-03 5/16 3/8 1/2 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 A500FI-0506-08
3/16 1/4 1/4 .3750 .0320 .1888 .1869 .2503 .2497 .1865 .1858 A350FI-0304-04 3/8 15/32 1/4 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A500FI-0607-04
1/4 5/16 3/8 .5000 .0320 .2518 .2495 .3128 .3122 .2490 .2481 A350FI-0405-06 3/8 15/32 3/8 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A500FI-0607-06
1/4 5/16 1/2 .5000 .0320 .2518 .2495 .3128 .3122 .2490 .2481 A350FI-0405-08 3/8 15/32 1/2 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A500FI-0607-08
5/16 3/8 1/4 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 A350FI-0506-04 3/8 15/32 3/4 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A500FI-0607-12
5/16 3/8 3/8 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 A350FI-0506-06 7/16 17/32 1/2 .7500 .0460 .4399 .4371 .5316 .5309 .4365 .4355 A500FI-0708-08
5/16 3/8 1/2 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 A350FI-0506-08 1/2 19/32 1/4 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A500FI-0809-04
3/8 15/32 1/4 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A350FI-0607-04 1/2 19/32 3/8 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A500FI-0809-06
3/8 15/32 3/8 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A350FI-0607-06 1/2 19/32 1/2 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A500FI-0809-08
3/8 15/32 1/2 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A350FI-0607-08 1/2 19/32 3/4 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A500FI-0809-12
3/8 15/32 3/4 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 A350FI-0607-12 1/2 19/32 1 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A500FI-0809-16
7/16 17/32 1/2 .7500 .0460 .4399 .4371 .5316 .5309 .4365 .4355 A350FI-0708-08 5/8 23/32 1/2 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 A500FI-1011-08
1/2 19/32 1/4 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A350FI-0809-04 5/8 23/32 3/4 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 A500FI-1011-12
1/2 19/32 3/8 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 A350FI-0809-06 5/8 23/32 1 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 A500FI-1011-16
3) After press-fit. Testing methods u Page 61 ASEAN 09/2023 ASEAN 09/2023 3) After press-fit. Testing methods u Page 61
