iglidur  A200                                                                                                                                                                                                            iglidur  A200
            ®
                                                                                                                                                                                                                                     ®
          +80°C                                                                                                                                                                                                                   +80°C
          18MPa                                                                                                                                                                                                                   18MPa
                      Bearing technology | Plain bearings | iglidur  A200                                                           Product range
                                                                                                 ®
          Flange bearings (form F)                                                                                                  d1      d1    d2   d3    b1  b2 Part No.            d1     d1    d2    d3   b1   b2 Part No.
                                                                         r max. 0.5                                                      Tolerance 3)  d13 3)  h13  h13                      Tolerance 3)  d13 3)  h13  h13
                                                                               f1
                                                                                                                                    [mm]         [mm] [mm] [mm] [mm]                    [mm]         [mm] [mm] [mm] [mm]
                                                                                 30°
                                                                                                                                    22.0         28.0 34.0 15.0 3.00 AFM-2228-15       27.0          34.0 40.0 40.0 4.00 AFM-2734-40
                                                                                                                                    22.0         28.0 34.0 20.0 3.00 AFM-2228-20       28.0          36.0 42.0 20.0 4.00 AFM-2836-20
                                                                d3  d1             d2
                                                                                                                                    22.0         28.0 34.0 30.0 3.00 AFM-2228-30       28.0  +0.065   36.0 42.0 30.0 4.00 AFM-2836-30
                                                                                                                                    24.0         30.0 36.0 15.0 3.00 AFM-2430-15       28.0  +0.195  36.0 42.0 40.0 4.00 AFM-2836-40
                                                                                                                                    24.0         30.0 36.0 20.0 3.00 AFM-2430-20       30.0          38.0 44.0 20.0 4.00 AFM-3038-20
                                                                   b2                                                                     +0.065
                                                                         b1                                                         24.0  +0.195  30.0 36.0 30.0 3.00 AFM-2430-30      30.0          38.0 44.0 30.0 4.00 AFM-3038-30
                                                                                                                                    25.0         32.0 38.0 20.0 4.00 AFM-2532-20       30.0          38.0 44.0 40.0 4.00 AFM-3038-40
                                                                                                                                    25.0         32.0 38.0 30.0 4.00 AFM-2532-30       32.0          40.0 46.0 20.0 4.00 AFM-3240-20
                                                             2)  Thickness < 0.6mm: chamfer = 20°                                                                                            +0.080
          Chamfer in relation to d1                                                                                                 25.0         32.0 38.0 40.0 4.00 AFM-2532-40       32.0  +0.240  40.0 46.0 30.0 4.00 AFM-3240-30
          d1 [mm]   Ø 1-6     Ø 6-12   Ø 12-30    Ø > 30           Dimensions according to ISO 2795 and special                     27.0         34.0 40.0 20.0 4.00 AFM-2734-20       32.0          40.0 46.0 40.0 4.00 AFM-3240-40
          f1 [mm]    0.3       0.5        0.8       1.2            dimensions                                                       27.0         34.0 40.0 30.0 4.00 AFM-2734-30
                                                                                                                                    3)  After press-fit. Testing methods, page 61
               Order example: AFM-0103-02 – no minimum order quantity.
               A200 iglidur  material F With flange M Metric 01 Inner Ø d1 03 Outer Ø d2 02 Total length b1
                         ®

           d1     d1    d2    d3   b1   b2 Part No.           d1     d1    d2    d3   b1   b2 Part No.
               Tolerance 3)  d13 3)  h13  h13                      Tolerance 3)  d13 3)  h13  h13
           [mm]        [mm] [mm] [mm] [mm]                    [mm]         [mm] [mm] [mm] [mm]
          1.0           3.0  5.0   2.0 1.00 AFM-0103-02       10.0         16.0 22.0  8.0 3.00 AFM-1016-08
          1.5   +0.020   4.0  6.0  2.0 1.00 AFM-0104-02       10.0  +0.040  16.0 22.0 10.0 3.00 AFM-1016-10
          2.0   +0.080  5.0  8.0   3.0 1.50 AFM-0205-03       10.0  +0.130 16.0 20.0 10.0 3.00 AFM-101620-10
          2.5           6.0  9.0   3.0 1.50 AFM-0206-03       10.0         16.0 22.0 16.0 3.00 AFM-1016-16
          3.0           6.0  9.0   4.0 1.50 AFM-0306-04       12.0         14.0 20.0 12.0 1.00 AFM-1214-12
          4.0           8.0  12.0  4.0 2.00 AFM-0408-04       12.0         18.0 24.0  8.0 3.00 AFM-1218-08
          4.0           8.0  12.0  6.0 2.00 AFM-0408-06       12.0         18.0 22.0 10.0 3.00 AFM-1218-10
          5.0           7.0  11.0  5.0 1.00 AFM-0507-05       12.0         18.0 24.0 12.0 3.00 AFM-1218-12
          5.0           9.0  13.0  5.0 2.00 AFM-0509-05       12.0         18.0 22.0 15.0 3.00 AFM-1218-15
          5.0   +0.030   9.0  13.0  6.0 2.00 AFM-0509-06      12.0         18.0 22.0 20.0 3.00 AFM-1218-20
          5.0   +0.105  9.0  13.0  8.0 2.00 AFM-0509-08       14.0         20.0 25.0 10.0 3.00 AFM-1420-10
          6.0          10.0 14.0   4.0 2.00 AFM-0610-04       14.0         20.0 25.0 15.0 3.00 AFM-1420-15
          6.0          10.0 14.0   6.0 2.00 AFM-0610-06       14.0         20.0 25.0 20.0 3.00 AFM-1420-20
          6.0          10.0 14.0 10.0 2.00 AFM-0610-10        15.0  +0.050   21.0 27.0 10.0 3.00 AFM-1521-10
          6.0          12.0 14.0   6.0 3.00 AFM-0612-06      15.0  +0.160  21.0 27.0 15.0 3.00 AFM-1521-15
          6.0          12.0 14.0 10.0 3.00 AFM-0612-10       15.0          21.0 27.0 20.0 3.00 AFM-1521-20
          7.0          11.0 15.0   8.0 2.00 AFM-0711-08      15.0          21.0 27.0 25.0 3.00 AFM-1521-25
          8.0          11.0 13.0   8.0 2.00 AFM-0811-08      16.0          22.0 28.0 12.0 3.00 AFM-1622-12
          8.0          12.0 16.0   6.0 2.00 AFM-0812-06      16.0          22.0 28.0 15.0 3.00 AFM-1622-15                               Available from stock                               Ordering note
          8.0          12.0 16.0   8.0 2.00 AFM-0812-08      16.0          22.0 28.0 20.0 3.00 AFM-1622-20                               Detailed information about delivery time online.   Our prices are scaled according to order
          8.0          12.0 16.0 12.0 2.00 AFM-0812-12       16.0          22.0 28.0 25.0 3.00 AFM-1622-25                               www.igus-asean.com/24                              quantities, current prices can be found online.
          8.0   +0.040  12.0 16.0 22.0 2.00 AFM-0812-22      18.0          24.0 30.0 12.0 3.00 AFM-1824-12                               Order online
          8.0   +0.130 14.0 18.0   6.0 3.00 AFM-0814-06      18.0          24.0 30.0 18.0 3.00 AFM-1824-18                               including delivery times, prices, online tools      Discount scaling
          8.0          14.0 18.0 10.0 3.00 AFM-0814-10       18.0          24.0 30.0 20.0 3.00 AFM-1824-20                               www.igus-asean.com/A200                             1-9           50-99         500-999
          9.0          14.0 19.0   6.0 2.00 AFM-0914-06      18.0          24.0 30.0 30.0 3.00 AFM-1824-30                                                                                   10-24         100-199       1,000-2,499
          9.0          14.0 19.0 10.0 2.00 AFM-0914-10       20.0  +0.065   26.0 32.0 15.0 3.00 AFM-2026-15                                                                                  25-49         200-499       2,500-4,999
          9.0          14.0 19.0 14.0 2.00 AFM-0914-14       20.0  +0.195  26.0 32.0 20.0 3.00 AFM-2026-20                                                                                  No minimum order value.
          10.0         16.0 22.0   6.0 3.00 AFM-1016-06      20.0          26.0 32.0 30.0 3.00 AFM-2026-30                                                                                  No low-quantity surcharges.
                                                                                                                 ASEAN 09/2023   ASEAN 09/2023                                              above €150.
          3)  After press-fit. Testing methods, page 61                                                                                                                                     Free shipping within Germany for orders
