Page 667 - IGUS Bearing

®
®
iglidur iglidur
®
knife- iglidur knife edge rollers | Product range knife-
edge- edge-
rollers rollers

Order key
d1 d1
Type Dimensions [mm]

d2 d2 b1 b1 Options:

iglidur material
®
P210: iglidur P210
®
● For particularly tight belt deflection A180: iglidur A180
®
● No production contamination caused by lubricants A350: iglidur A350
®
● Hygienic design without ball or needle rollers iglidur ® material H1: iglidur H1
®
● Easy to clean Inner Ø Outer Ø Total length
● Suitable for direct contact with food Roller Metric
● Resistant to temperature and chemicals

Knife edge rollers made from iglidur P210 - universal, up to +100°C Knife edge rollers made from iglidur A250 - wear-resistant conveyor belt support, up to +90°C
®
®
d1 +0.1 [mm] d2 147) ±0.1 [mm] b1 -0.3 [mm] Part No. d1 +0.1 [mm] d2 147) ±0.1 [mm] b1 -0.3 [mm] Part No.
3.1 9.0 50.0 P210RLM-0309-50 4.1 9.0 50.0 A250RLM-0409-50 New
4.1 9.0 50.0 P210RLM-0409-50 6.1 12.0 70.0 A250RLM-0612-70 New
5.1 11.0 70.0 P210RLM-0511-70 8.1 12.0 70.0 A250RLM-0812-70 New
5.1 14.0 70.0 P210RLM-0514-70 8.1 14.0 70.0 A250RLM-0814-70 New
6.1 12.0 70.0 P210RLM-0612-70 8.1 16.0 70.0 A250RLM-0816-70 New
6.1 14.0 70.0 P210RLM-0614-70
8.1 12.0 70.0 P210RLM-0812-70
8.1 14.0 70.0 P210RLM-0814-70 Knife edge rollers made from iglidur A350 - FDA-compliant, up to +180°C
®
8.1 16.0 77.0 P210RLM-0816-77 147)
8.1 18.0 70.0 P210RLM-0818-70 d1 +0.1 [mm] d2 ±0.1 [mm] b1 -0.3 [mm] Part No.
10.1 20.0 70.0 P210RLM-1020-70 3.1 9.0 50.0 A350RLM-0309-50
6.1 12.0 70.0 A350RLM-0612-70
6.1 14.0 70.0 A350RLM-0614-70
Knife edge rollers made from iglidur A180 - FDA-compliant, up to +90°C 8.1 18.0 70.0 A350RLM-0818-70
®
d1 +0.1 [mm] d2 147) ±0.1 [mm] b1 -0.3 [mm] Part No.
3.1 9.0 50.0 A180RLM-0309-50
®
4.1 9.0 50.0 A180RLM-0409-50 Knife edge rollers made from iglidur H1 for higher transport speeds, up to +200°C
5.1 11.0 70.0 A180RLM-0511-70 d1 +0.1 [mm] d2 147) ±0.1 [mm] b1 -0.3 [mm] Part No.
5.1 14.0 70.0 A180RLM-0514-70 3.1 9.0 50.0 H1RLM-0309-50
6.1 12.0 70.0 A180RLM-0612-70 4.1 9.0 50.0 H1RLM-0409-50
6.1 14.0 70.0 A180RLM-0614-70 5.1 11.0 70.0 H1RLM-0511-70
8.1 12.0 70.0 A180RLM-0812-70 6.1 12.0 70.0 H1RLM-0612-70
8.1 14.0 70.0 A180RLM-0814-70 6.1 14.0 70.0 H1RLM-0614-70
8.1 18.0 70.0 A180RLM-0818-70 8.1 12.0 70.0 H1RLM-0812-70
10.1 20.0 70.0 A180RLM-1020-70 8.1 14.0 70.0 H1RLM-0814-70

147) Measured with gauge ASEAN 09/2023 ASEAN 09/2023 147) Measured with gauge

664 Online tools and more information u www.igus-asean.com/RLM 3D CAD files, prices and delivery time online u www.igus-asean.com/RLM 665
