iglidur two iglidur two
®
®
®
®
hole flange iglidur two hole flange bearings | Advantages iglidur two hole flange bearings | Product range hole flange
bearings bearings
Maintenance-free dry operation Two hole flange bearings
iglidur - maintenance- d6 R Order key
®

iglidur G: free two hole flange d5 Type Dimensions [mm]
®
Standard material for d1
all-round applications bearings d2

With this design it is possible to use iglidur high b1 Options:
®
iglidur material
®
performance plain bearings in locations where b2 d4 b3 G: iglidur G
®
d7
recommended housing hole tolerances are not d3 Two hole flange bearings J: iglidur J
®
possible. Due to the design of the bearing, high iglidur ® material X: iglidur X
®
iglidur J: loads are possible although there is a minimal Inner Ø A180: iglidur A180
®
®
Material for low wear precision requirement of the housing.
● Very good wear resistance Dimensions [mm]
● Lightweight
● Lubrication-free d1 d1 tolerance 3) d2 13) d3 d4 d5 d6 d7 b1 b2 b3 R Part No.
(±0.2)
®
iglidur X: Assembly 10 +0.025 +0.083 12 30 14 15 4.5 22 6 2 1 4 GFL-10
Material for high For low radial loads, it is sufficient to mount 12 +0.032 +0.102 14 36 16 18 4.5 26 6 2 1 4.5 GFL-12
temperature applications iglidur two hole flange bearings on one surface 14 +0.032 +0.102 16 42 18 21 5.5 30 6 2 1 5 GFL-14
®
simply with two bolts. For higher radial loads, it 16 +0.032 +0.102 18 48 20 24 5.5 34 6 2 1 5.5 GFL-16
advisable to support the iglidur two hole flange 18 +0.032 +0.102 20 54 22 27 6.5 39 6 2 1 7 GFL-18
®
bearing in a housing or boss. For this hole, large 20 +0.040 +0.124 23 60 26 30 6.5 44 10 3 2 7 GFL-20
tolerances are permitted, since it serves only as 25 +0.040 +0.124 28 75 30 35 6.5 55 10 3 2 8.5 GFL-25
iglidur A180 additional support for the iglidur two hole flange 30 +0.040 +0.124 34 90 36 40 8.5 66 10 3 2 10 GFL-30
®
®
Material for use in the bearing. In order to achieve higher radial loads in 35 +0.050 +0.150 39 95 41 55 8.5 77 10 3 2 12 GFL-35
®
food sector the bearings, the iglidur two hole flange bearing 10 +0.025 +0.083 12 30 14 15 4.5 22 6 2 1 4 JFL-10
can be press-fit into a recommended housing 12 +0.032 +0.102 14 36 16 18 4.5 26 6 2 1 4.5 JFL-12
hole with H7 tolerances. The additional bolts 14 +0.032 +0.102 16 42 18 21 5.5 30 6 2 1 5 JFL-14
ensure the fit of the bearing in the housing. 16 +0.032 +0.102 18 48 20 24 5.5 34 6 2 1 5.5 JFL-16
20 +0.040 +0.124 23 60 26 30 6.5 44 10 3 2 7 JFL-20
iglidur J: 25 +0.040 +0.124 28 75 30 35 6.5 55 10 3 2 8.5 JFL-25
®
Two hole flanged bearing 30 +0.040 +0.124 34 90 36 40 8.5 66 10 3 2 10 JFL-30
with preload 35 +0.050 +0.150 39 95 41 55 8.5 77 10 3 2 12 JFL-35
10 +0.013 +0.071 12 30 14 15 4.5 22 6 2 1 4 XFL-10
12 +0.016 +0.086 14 36 16 18 4.5 26 6 2 1 4.5 XFL-12
14 +0.016 +0.086 16 42 18 21 5.5 30 6 2 1 5 XFL-14
16 +0.016 +0.086 18 48 20 24 5.5 34 6 2 1 5.5 XFL-16
20 +0.020 +0.104 23 60 26 30 6.5 44 10 3 2 7 XFL-20
Available from stock Material properties: 25 +0.020 +0.104 28 75 30 35 6.5 55 10 3 2 8.5 XFL-25
®
Detailed information about delivery time online. iglidur G u Page 85 30 +0.020 +0.104 34 90 36 40 8.5 66 10 3 2 10 XFL-30
®
iglidur J u Page 163 35 +0.025 +0.125 39 95 41 55 8.5 77 10 3 2 12 XFL-35
®
Depending on material: iglidur X u Page 291 10 +0.025 +0.083 12 30 14 15 4.5 22 6 2 1 4 A180FL-10
®
iglidur G: -40°C up to +130°C iglidur A180 u Page 425 12 +0.032 +0.102 14 36 16 18 4.5 26 6 2 1 4.5 A180FL-12
®
iglidur J: -50°C up to +90°C 16 +0.032 +0.102 18 48 20 24 5.5 34 6 2 1 5.5 A180FL-16
®
iglidur X: -100°C up to +250°C Ø 10 - 35mm 20 +0.040 +0.124 23 60 26 30 6.5 44 10 3 2 7 A180FL-20
®
iglidur A180: -50°C up to +90°C More dimensions upon request 30 +0.040 +0.124 34 90 36 40 8.5 55 10 3 2 8.5 A180FL-25
®
75
25
+0.040 +0.124
28
30
6.5
35
2
10
A180FL-30
10
3
66
ASEAN 09/2023 ASEAN 09/2023 3) 35 +0.050 +0.150 39 95 41 13) 55 8.5 77 10 3 2 12 A180FL-35
After press-fit. Testing methods u Page 57 Press-fit in H7 tolerance housing hole
668 Online tools and more information u www.igus-asean.com/two-hole-flange-bearings 3D CAD files, prices and delivery times online u www.igus-asean.com/two-hole-flange-bearings 669
