Page 901 - IGUS Bearing

igubal igubal
®
®
®
®
angled ball igubal angled ball and socket joints | Product range igubal angled ball and socket joints | Product range angled ball
and socket and socket
joint joint
Angled ball and socket joints: Angled ball and socket joints (low-cost):
WGRM and WGLM Order key WGRM-LC and WGLM-LC Order key

● Connection for rotating and Type Size Type Size Version
pivoting movements
● Lightweight
● Easy and quick assembly
● Vibration-dampening
● Insensitive to dirt and dust
● Ball studs made of plastic,
galvanised steel and stainless Thread size M ... [mm] Thread size M ... [mm]
steel Angled ball and socket joint Thread (housing) Angled ball and socket joint Thread (housing)
19)
u Accessories, page 1011 Metric Metric Low-cost

b d4 l5 d1
a e Options: ● Housing with ball stud Options:
Thread (housing) Ball stud 19) ● Lightweight Thread (housing) Ball stud 19)
h1 S1 d2 L : Left-hand thread Blank : Made of plastic ● Maintenance-free L : Left-hand thread Blank : Made of plastic
h2 l1
h3 R : Right-hand thread MS : Made of galvanised ● Ball studs made of plastic, galvanised steel and R : Right-hand thread MS : Made of galvanised

19)
l6 l2 steel stainless steel u Accessories, page 1011 steel
d2 ES : Made of stainless ES : Made of stainless
S2 steel 28) steel 28)

Online service life calculation Material: Online service life calculation Material:
®
u www.igus-asean.com/igubal-expert Housing: igumid G u Page 1190 u www.igus-asean.com/igubal-expert Housing: igumid G u Page 1190
®
Spherical cap: iglidur W300 u Page 175
®
Technical data
Technical data Part No. Max. static Max. static Max. axial Max. axial tensile Weight
Part No. Max. static Max. static Max. axial Max. axial tensile Weight tensile force compressive strength tensile force force steel stud
tensile force compressive strength tensile force force steel stud (Ball stud axis) (Ball stud axis) (Housing axis) (Housing axis)
(Ball stud axis) (Ball stud axis) (Housing axis) (Housing axis) Short-term Long-term Short-term Long-term Short-term Long-term Short-term Long-term
Short-term Long-term Short-term Long-term Short-term Long-term Short-term Long-term [N] [N] [N] [N] [N] [N] [N] [N] [g]
[N] [N] [N] [N] [N] [N] [N] [N] [g] WG M-04-LC-MS 20) 100 50 150 75 – – 500 250 2.4
WG M-05-MS 30 15 200 100 100 50 600 300 2.6 WG M-05-LC-MS 150 75 200 100 100 50 600 300 2.6
WG M-06-MS 35 17.5 300 150 140 70 800 400 3.8 WG M-06-LC-MS 200 100 300 150 140 70 800 400 4.0
WG M-08-MS 250 125 500 250 200 100 1,500 750 8.0 WG M-08-LC-MS 250 125 500 250 200 100 1,500 750 8.2
WG M-10-MS 250 125 900 450 400 200 1,900 950 13.7 WG M-10-LC-MS 250 125 900 450 400 200 1,900 950 13.8

Dimensions [mm] Dimensions [mm] - technical drawing u Page 898
Part No. d1 d2 d4 l1 l2 l5 l6 h1 h2 h3 a b e S1 S2 Max. Part No. d1 d2 d4 l1 l2 l5 l6 h1 h2 h3 a b e S1 S2 Max.
±0.1 ±0.5 ±0.2 ±0.3 min. ±0.4 ±0.5 ±0.5 ±0.3 ±0.5 ±1.0 pivot ±0.1 ±0.5 ±0.2 ±0.3 min. ±0.4 ±0.5 ±0.5 ±0.3 ±0.5 ±1.0 pivot
angle angle
WG M-05-MS 8 M5 12.8 9 10.2 14 6.2 10.8 0.65 24.9 22 28.4 11 SW8 SW7 25° WG M-04-LC-MS 20) 6 M4 10.6 8.5 8.0 11.9 6.8 9.0 0.20 21.8 18 23.3 10.5 SW7 SW5 20°
WG M-06-MS 10 M6 14.8 11 12.5 16 9.0 12.3 0.70 30.9 25 32.4 13 SW9 SW8 25° WG M-05-LC-MS 8 M5 12.8 9.0 10.2 14.0 6.2 10.8 0.65 24.9 22 28.4 11.0 SW8 SW7 25°
WG M-08-MS 13 M8 19.3 13 16.5 18 11.2 16.2 1.15 39.15 30 39.7 16 SW12 SW11 25° WG M-06-LC-MS 10 M6 14.8 11.0 12.5 16.0 9.0 12.3 0.70 30.9 25 32.4 13.0 SW9 SW8 25°
WG M-10-MS 16 M10 24.0 16 20.0 20 12.7 20.0 1.15 48.0 35 47.0 18 SW14 SW13 25° WG M-08-LC-MS 13 M8 19.3 13.0 16.5 18.0 11.2 16.2 1.15 39.15 30 39.7 16.0 SW12 SW11 25°
19) Ball stud with right-hand thread; left-hand thread upon request WG M-10-LC-MS 16 M10 24.0 16.0 20.0 20.0 12.7 20.0 1.15 48.0 35 47.0 18.0 SW14 SW13 25°
ASEAN 09/2023 ASEAN 09/2023 20) Only available with galvanised steel stud
28) Stainless steel ball stud upon request 19) Ball stud with right-hand thread; left-hand thread upon request

Stainless steel ball stud upon request
28)
898 Online tools and more information u www.igus-asean.com/rod-ends 3D CAD files, prices and delivery times online u www.igus-asean.com/rod-ends 899
