igubal igubal
®
®
®
®
pillow block igubal pillow block bearings | Product range igubal pillow block bearings | Product range New pillow block
bearings bearings
Pillow block bearings Slim Line: ESTM SL Compact pillow block bearings: PA-KS-JEM-SP
Order key Order key

Type Size Version Type Size Version

h1 a

C1 Pillow block bearing m Pillow block bearing Spherical ball material Spherical ball inner Ø [mm] Spherical ball width [mm]

d1 E series Metric Inner Ø [mm] Slim Line Dimensional series Injection moulding
h Polymer Metric
R1
Material: C2

Housing: igumid G u Page 1190 Material:
®
Spherical ball: iglidur J u Page 163 Housing: igumid G u Page 1190
®
®
Spherical ball: iglidur J u Page 163
®
● Extremely lightweight
h2 ● Space-saving h2 d1 ● Extremely lightweight
d2 ● Cost-effective h1 ● Space-saving
m ● Predictable service life l1 ● Cost-effective
a ● Maintenance-free and lubrication-free B ● Predictable service life
● With M3 thread, e. g. ESTM-10-SL-M3 d2 ● Maintenance-free and lubrication-free
C1
Online service life calculation ● For self tapping screw with outer diameter 3.5mm ● Dimensional series E following DIN ISO 12240
u www.igus-asean.com/igubal-expert ● Dimensional series E following DIN ISO 12240
Technical data

Part No. Max. static Max. static Weight
radial tensile strain axial compressive force
Technical data Short-term Long-term Short-term Long-term
Part No. Max. radial Max. radial Max. lateral Max. axial Weight [N] [N] [N] [N] [g]
tensile force compressive strength strength strength PA203-KS-JEM-17-17-SP New 7,500 3,750 1,100 550 85.3
Short-term Long-term Short-term Long-term Short-term Long-term Short-term Long-term PA204-KS-JEM-20-17-SP New 7,500 3,750 1,100 550 85.3
[N] [N] [N] [N] [N] [N] [N] [N] [g] PA205-KS-JEM-25-17-SP New 8,000 4,000 2,300 1,150 103.6
ESTM-05-SL-M3 1,500 750 1,400 700 900 450 150 75 1.6 PA206-KS-JEM-30-19-SP New 13,500 6,750 2,500 1,250 164.0
ESTM-06-SL-M3 1,500 750 1,400 700 900 450 150 75 1.7 PA207-KS-JEM-35-20-SP New – – – – 219.3
ESTM-08-SL-M3 1,600 800 1,400 700 950 475 100 50 1.7 PA208-KS-JEM-40-21-SP New – – – – 217.4
ESTM-10-SL-M3 1,600 800 1,400 700 1,000 500 100 50 1.9 PA210-KS-JEM-50-24-SP New – – – – 284.1

Dimensions [mm] Dimensions [mm]
Part No. d1 d2 h h1 h2 a m C1 R1 Max. Part No. d1 d2 h1 h2 l1 B C1 C2 m a
E10 pivot angle
ESTM-05-SL-M3 5 2.5 18 10 6.5 16 10 6 8 17° PA203-KS-JEM-17-17-SP New 17 M10 30.2 31.2 13 17 32 25.4 52 70
ESTM-06-SL-M3 6 2.5 18 10 6.5 16 10 6 8 17° PA204-KS-JEM-20-17-SP New 20 M10 30.2 31.2 13 17 32 25.4 52 70
ESTM-08-SL-M3 8 2.5 19 10 6.5 18 12 6 9 17° PA205-KS-JEM-25-17-SP New 25 M10 36.5 70.6 15 17 34 27.5 56 74
ESTM-10-SL-M3 10 2.5 20 10 6.5 20 14 6 10 17° PA206-KS-JEM-30-19-SP New 30 M14 42.9 82.9 18 19 38 30.0 66 89
PA207-KS-JEM-35-20-SP New 35 M14 47.6 92.6 21 20 38 30.0 80 103
ASEAN 09/2023 ASEAN 09/2023 PA210-KS-JEM-50-24-SP New 50 M16 57.2 110.2 26 24 41 33.0 94 119
39
PA208-KS-JEM-40-21-SP New
107
84
31.0
97.2
49.2
M14
21
21
40
934 Online tools and more information u www.igus-asean.com/pillow-block 3D CAD files, prices and delivery times online u www.igus-asean.com/pillow-block 935
