drylin drylin shafts | Product range drylin shafts | Product range drylin
®
®
®
®
shafts shafts
Precision aluminium shafts Supported aluminium shafts
Order key Order key

Type Size Options Type Size Options

AWMP:
Solid shaft up to
Aluminium shaft Shaft length Hollow shaft from Aluminium shaft Supported Shaft length
Ø25mm

Ø30mm

AWMR AWMP Metric Precision Outer Ø [mm] AWMR: AWMU Metric Outer Ø [mm]
Tube
D
®
igus recommendation: linear plain bearings Hard anodised surfaces ● Material: EN AW 6061/6060 Hard anodised surfaces
equipped with iglidur J200 liners for u Page 43 ● Straightness: DIN 12020 u Page 43
®
the longest service life Minimum saw lengths ● Hardness: 75 HB Minimum saw lengths ød1 H
u Page 47 ● Surface: hard anodised u Page 47 ° V
● Hardness: up to 550 HV E B
● Material: EN AW 6061/6060 Please contact us! Symmetrical standard hole pattern C5 = C6 D max. 4.000
● Straightness: EN 754-3 drylin shafts can be individually machined. Please ●
®
● Hardness: 75 HB send us your drawing or make the configuration
● Surface: hard anodised online. We can then provide a quick quotation. ød1 H
● Hardness: up to 550 HV u www.igus-asean.com/shaft-configurator ° V
● Imperial shafts available upon request B E C5 T1 C6
max. 4.000

Dimensions [mm] Dimensions [mm]

Part No. Design Outer Ø Tolerance Wall Inner Ø Max. Weight Part No. D B H V d1 (º) E T1 C5/C6 Max. Weight ly lz Wby Wbz
thickness length [kg/m] -0.1 ±0.25 ±0.25 min. max. length [kg/m] [mm ] [mm ] [mm ] [mm ]
2
2
4
4
26,600
AWMP-06 Solid shaft 6 h8 – – 3,000 0.08 AWMU-12 12 40 22 5 4.5 50 29 75 C5 20 57 T1 4,000 0.75 C6 19,700 1,330 1,091
AWMP-08 Solid shaft 8 h8 – – 3,000 0.14 AWMU-16 16 45 26 5 5.5 50 33 100 20 69 4,000 1.00 40,000 39,200 1,778 1,844
AWMP-10 Solid shaft 10 h8 – – 3,000 0.22 AWMU-20 20 52 32 6 6.6 50 37 100 20 69 4,000 1.42 76,600 86,200 2,946 3,336
AWMP-12 Solid shaft 12 h8 – – 3,000 0.32 AWMU-25 25 57 36 6 6.6 50 42 120 20 79 4,000 1.81 109,800 146,700 3,853 5,103
AWMR-12 Tube 12 h8 2 8 3,000 0.17 AWMU-30 30 69 42 7 9.0 50 51 150 20 94 4,000 2.69 226,900 328,700 6,577 10,049
AWMP-16 Solid shaft 16 h8 – – 3,000 0.56 AWMU-40 86) 40 73 50 8 9.0 50 55 200 20 119 4,000 4.06 382,100 734,800 10,468 19,160
AWMR-16 Tube 16 h8 2 12 3,000 0.25 86) The tolerance for the shaft diameter D amounts -0.15
AWMP-20 Solid shaft 20 h8 – – 3,000 0.88
AWMR-20 Tube 20 h9 2 16 3,000 0.32
AWMP-25 Solid shaft 25 h8 – – 3,000 1.37
AWMR-25 Tube 25 h9 3 19 3,000 0.59
AWMP-30 Hollow shaft 30 h8 7.5 15 3,000 1.48
AWMPV-30 Solid shaft 30 h8 – – 3,000 1.9
AWMP-40 Hollow shaft 40 h8 10 20 3,000 2.63
AWMPV-40 Solid shaft 40 h8 – – 3,000 3.4
AWMP-50 Hollow shaft 50 h8 11 28 3,000 3.75
AWMP-60 Hollow shaft 60 h8 11 38 3,000 4.7

Order example: Order example:
AWMP-12-500: precision aluminium shaft, 12mm Ø, 500mm length ASEAN 09/2023 ASEAN 09/2023 AWMU-16-500: supported aluminium shaft, 16mm Ø, 500mm length
268 Online tools and more information u www.igus-asean.com/shafts 3D CAD files, prices and delivery time online u www.igus-asean.com/shafts 269
