drylin       drylin  shafts | Product range                                                                              drylin  shafts | Product range                                                                   drylin
             ®
                               ®
                                                                                                                                                                                                                                       ®
                                                                                                                                           ®
        shafts                                                                                                                                                                                                                    shafts
                     Partially supported stainless steel shafts
                                                                         D
                                                                          F                                                                                                                  Order key


                                                                                                                                                                                       Type                Size   Options

                                                               Ød1
                                                                                         H
                                                                                     V
                                                                     D
                                                                      F  ( )
                                                                          E
        EWUM-ES/                                                                                                                                                                           Partially supported   stainless steel shaft,
                                                               Ød1        B
        EWUMS-ES                                                             V  H                                                                                                                                   Shaft length    Hole pattern
                                                                     ( )    G                                                                                                                   metric  Material  Outer Ø  [mm]
                                                                      E
                  ®
               igus  recommendation: linear plain bearings            B
               equipped with iglidur  E7 liners for 8 times            G                                                                                                              Available materials and lengths:
                                  ®
               longer service life                                                                                                                                                    AISI 440B, max 6,000mm
                                                                                                                                                                                      u EWUM
                                                                                                                                                                                      AISI 316Ti, max 3,000mm
        Standard shaft support blocks made of stainless steel                                                                                                                         u EWUMS
        ● 	Connection sizes are identical to aluminium supports
           u Page 274                                              C5  C5     T1/T2      T               C6                     C6
                                                                                                                                                                                      Options:
                                                                                                                                                                                      Blank: AISI 440B material
                                                                                                                                                                                      S: AISI 316Ti
                                                                                                                                                                                      Hole pattern:
                                                                                                                                                                                      T2: T2 pitch (standard)
                                                                                                                                                                                      T1: T1 pitch









        Dimensions [mm] - partially supported stainless steel shafts AISI 440B                                                   Dimensions [mm] - partially supported stainless steel shafts AISI 316Ti
         Part No.         D     B     H     V    d1    E    ϒ     F     G    T1     C5/C6      T2      C5/C6                     Part No.          D    B     H     V    d1    E     ϒ    F     G    T1     C5/C6      T2      C5/C6
                          h6        ±0.02                                           for T1   Standard   for T2                                    h6         ±0.02                                           for T1  Standard   for T2
                                                                                  min.  max.         min.  max.                                                                                           min.  max.          min.  max.
         EWUM-ES-12       12    40   22     5   4.5   29     –   5.8   14    75    20   57     120    20    79                   EWUMS-ES-12      12    40   22     5    4.5   29    –    5.8   14   75    20    57    120    20    79
         EWUM-ES-16       16    45   26     5   5.5   33     –   7.0   16   100    20   69     150    20    94                   EWUMS-ES-16      16    45    26    5    5.5   33    –    7.0   16   100   20    69    150    20    94
         EWUM-ES-20       20    52   32     6   6.6   37    50°  8.3   20   100    20   69     150    20    94                   EWUMS-ES-20      20    52    32    6    6.6   37   50°   8.3   20   100   20    69    150    20    94
         EWUM-ES-25       25    57   36     6   6.6   42     –   10.8  25   150    20   79     200    20   119                   EWUMS-ES-25      25    57    36    6    6.6   42    –   10.8   25   150   20    79    200    20   119
         EWUM-ES-30       30    69   42     7   9.0   51     –   11.0  25   150    20   94     200    20   119                   EWUMS-ES-30      30    69    42    7    9.0   51    –   11.0   25   150   20    94    200    20   119
         EWUM-ES-40       40    73   50     8   9.0   55     –   15.0  25   200    20   119    300    20   169                   EWUMS-ES-40      40    73    50    8    9.0   55    –   15.0   25   200   20   119    300    20   169








               Order example:                                                                                                          Order example:
               EWUM-ES-20-500, partially supported stainless steel shaft (shaft and support made of stainless steel),                  EWUMS-ES-20-500, partially supported stainless steel shaft (shaft and support made of stainless steel),
                                                                                                                   ASEAN 09/2023  ASEAN 09/2023
               AISI 440B material, T2 pitch, outer Ø 20mm, L = 500mm                                                                   AISI 316Ti material, T1 pitch, outer Ø 20mm, L = 500mm



        276 Online tools and more information u www.igus-asean.com/shafts                                                                    3D CAD files, prices and delivery time online u www.igus-asean.com/shafts              277
