Lead screw nuts for linear modules
Square lead screw nuts Lead screw nuts with flange
Order key Order key

Order example Order example

DST-SHT-1210 SHT-1210-TR DST-SHT-2018 SHT-2018-TR

(32)
8.5 8.5
15 - 0.3 (21) 2×45° dryspin ® geometry SHT linear module Installation size iglidur ® material Hand of rotation n 6 n 6 dryspin ® geometry SHT linear module Installation size iglidur ® material Hand of rotation
Thread
46
33
A
A
16.5 46 33 16.5 d1 d1 Ø28 Ø28 Thread
Options: Options:
(16)
Hand of rotation 19 19 12 12 Hand of rotation
12.5 ±2 Z
(identification RH: Right-Hand 32 32 34 34 RH: Right-Hand
groove, 2×45°
any shape) LH: Left-hand LH: Left-hand
Please note: not symmetrical
Dimensions Dimensions
(Ø5.5)
Part No. Direction of Thread Max. stat. axial F [N] Weight [g] From SLW Part No. Direction of Thread Max. stat. axial F [N] Weight [g] From SLW
rotation d1xP iglidur ® iglidur ® linear module rotation d1xP iglidur ® iglidur ® linear module
Right Left J A180 J A180 Right Left J A180 J A180
DST-SHT-1210-DS10X2- - A-A Ds10x2 750 750 10 10 SHT-12 u Page 524 DST-SHT-2018-DS18X4- - Ds18x4 2,400 2,400 32 36 SHT-20 u Page 524
(5.4)
DST-SHT-1210-DS10X3- - Ds10x3 1,000 1,000 10 10 SHT-12 u Page 524 DST-SHT-2018-DS18X24- - Ds18x24 1,688 1,688 32 36 SHT-20 u Page 524
DST-SHT-1210-DS10X12- - Ds10x12 700 700 10 10 SHT-12 u Page 524 DST-SHT-2018-DS18X40- - Ds18x40 1,528 1,528 32 36 SHT-20 u Page 524
(Ø9) Thread
DST-SHT-1210-DS10X25- - Ds10x25 625 625 10 10 SHT-12 u Page 524 DST-SHT-2018-DS18X80- - Ds18x80 1,056 1,056 32 36 SHT-20 u Page 524
DST-SHT-1210-DS10X50- - Ds10x50 370 370 10 10 SHT-12 u Page 524 DST-SHT-2018-DS18X100- - Ds18x100 985 985 32 36 SHT-20 u Page 524
SHT-1210-DS10X2- - Tr10x2 750 750 10 10 SHT-12 u Page 524 SHT-2018-TR18X4- - Tr18x4 2,400 2,400 32 36 SHT-20 u Page 524
SHT-1210-DS10X3- - Tr10x3 910 910 10 10 SHT-12 u Page 524 SHT-2018-TRM18X8P4- - Tr18x8p4 1,960 1,960 32 36 SHT-20 u Page 524

Part number suffix LH for left-hand thread, RH for right-hand thread Part number suffix LH for left-hand thread, RH for right-hand thread
From SHT linear module SHT-12 u Page 524 From SHT linear module SHT-20 u Page 524

Assembly instructions u Page 368 Assembly instructions u Page 368
and u www.igus-asean.com/dryspin-assembly-instructions and u www.igus-asean.com/dryspin-assembly-instructions
