dryspin dryspin
®
®
®
®
lead screw dryspin | Special geometries | Product range dryspin | Special geometries | Product range lead screw
technology technology
Lead screw nuts with locating spigot
Ø 20
Ø15
3 8
17.5 d1xP 33 d1xP

5x45°
20 5x45°
DST-SLW-1040 SWZ-W-10XX 20 DST-SLW-2080 SWZ-W-20XX 30 30

SWZ-W-2080..

Dimensions

Part No. Hand of Thread Max. stat. Weight From SLW Part No. Hand of Thread Max. stat. Weight From SLW
rotation d1xP axial F linear module rotation d1xP axial F linear module
Right Left [N] [g] Right Left [N] [g]
DST-SLW-1040-DS10X2-J- New Ds10x2 747 8 SLW-1040 u Page 538 DST-SLW-2080-DS18X4-J- New Ds18x4 2,513 30 SLW-2080 u Page 538
DST-SLW-1040-DS10X3-J- New Ds10x3 1,005 8 SLW-1040 u Page 538 DST-SLW-2080-DS18X24-J- Ds18x24 1,747 30 SLW-2080 u Page 538
DST-SLW-1040-DS10X12-J- Ds10x12 686 8 SLW-1040 u Page 538 DST-SLW-2080-DS18X40-J- Ds18x40 1,638 30 SLW-2080 u Page 538
DST-SLW-1040-DS10X25-J- Ds10x25 623 8 SLW-1040 u Page 538 DST-SLW-2080-DS18X80-J- Ds18x80 1,130 30 SLW-2080 u Page 538
DST-SLW-1040-DS10X50-J- Ds10x50 361 8 SLW-1040 u Page 538 DST-SLW-2080-DS18X100-J- Ds18x100 992 30 SLW-2080 u Page 538
SLW-1040-TR10X2-J- Tr10x2 1,131 8 SLW-1040 u Page 538 SLW-2080-TR18X4-J- Tr18x4 2,513 30 SLW-2080 u Page 538
SLW-1040-TR10X3-J- TR10x3 1,068 8 SLW-1040 u Page 538 SLW-2080-TR18X8P4-J- Tr18x8P4 2,991 30 SLW-2080 u Page 538

(5.8)
d1xP
4 ( x45°)

7.8
(8) (20) (17)
n

(20)
SWZ-W-16XX (n 25) (25.8)
(5.8)
d1xP
4 ( x45°)

7.8
(8) (20) (17)
n

(20)
(n 25) (25.8)

Dimensions

Part No. Hand of rotation Thread Max. stat. Weight From SLW
Right Left d1xP axial F [N] [g] linear module
DST-SLW-1660-DS14X4-J- Ds14x4 952 13 SLW-1660 u Page 538
DST-SLW-1660-DS14X25-J- Ds14x25 825 13 SLW-1660 u Page 538
DST-SLW-1660-DS14X30-J- Ds14x30 825 13 SLW-1660 u Page 538
SLW-1660-TR14X3-J- Tr14x3 1,570 13 SLW-1660 u Page 538
