drylin drive technology | Application examples
®

Camera/laser adjustment in labelling system
In a labelling system the camera and laser positioning Pick & place ®
are guided with two drylin SHT/SLWE-XY XY table Quick and maintenance-free handling with drylin toothed
®
units. (Fa. Pago Etikettiersysteme GmbH) belt axes as a room linear robot (X, Y, Z-axis).

Positioning of milling heads Electric actuator
Aluminium dust and swarf cannot stick due to the drylin linear module combined with an electric
®
absence of lubricants at any of the bearing points of the actuator for use in a variety of format adjustments.
drylin SHT linear module. (Berchtold GmbH) (Festo AG & Co. KG)
®

Height adjustment of coding device
The drylin linear module gives variable and precise Adjustment of inspection camera
®
®
adjustment, free from any maintenance or lubrication. drylin ZLW toothed belt axis in an inspection camera
(Filtec Europe GmbH) adjustment for checking the position of sealing rings.
(OLPE Jena GmbH)
