drylin drive technology | Product overview
®
drylin drive technology - SHT linear modules
®
®
Self-locking: Axial pre-load, Compact design: The fast one with dryspin With ball bearing Made of stainless steel: Hygienic design: With quick-release
radial adjustment: high helix thread: supported lead screw: mechanism:
SHT SHT-PL SHTC SHTS SHT-BB SHT-ESJ SHTC-HYD SHTC-FF
u Page 524 u Page 525 u Page 526 u Page 527 u Page 528 u Page 530 u Page 531 u Page 532
SHT linear modules SLW linear modules
New
®
With quick-release XY tables: Self-locking: With short carriages: Axial pre-load, radial With ball bearing The fast one with dryspin With protected
mechanism: adjustment: supported lead screws: high helix thread: lead screw:
SHT-FF SHT-XY SLW SLWC SLWE-PL SLEW-BB SLWS SLW-PT
u Page 533 u Page 534 u Page 538 u Page 540 u Page 541 u Page 542 u Page 544 u Page 546
SLW linear modules SAW linear modules
Dual action Stainless steel version: XY tables: XY tables - stainless steel Robust design: Clearance-reduced Direct drive in short
linear system: version: with pre-load: design:
SLWT SLW-ES SLW-XY SLW-XY-ES SAW SAW-PL SAWC
u Page 547 u Page 548 u Page 550 u Page 552 u Page 556 u Page 557 u Page 558
easytube linear units Flat linear modules
Single tube linear unit easytube with double easytube with single easytube with easytube "light": Ball bearing supported lead
easytube: flange: flange: measurement scale: screws based on drylin T:
®
SET SET-F SETB SETM-SC SETC SLT-BB
u Page 562 u Page 563 u Page 564 u Page 565 u Page 566 u Page 569
Miniature linear modules ZLW toothed belt axes
New
Pre-load miniature Prism module for precise Standard toothed belt Modular Linear axis with hygienic Tandem Opposite drive toothed Cost-effective econ
linear module: adjustment: axes: toothed belt axes: design: toothed belt axis: belt axes: toothed belt axis:
SLN-27 SLNV ZLW ZLW-AL/-ES ZLW-HYD ZLWT ZLW-OD ZLN econ
u Page 573 u Page 574 u Page 586 u Page 588 ASEAN 09/2023 ASEAN 09/2023 u Page 590 u Page 591 u Page 592 u Page 594
