drylin drylin econ | Linear modules | Product range drylin econ | Linear axes | ZLW econ drylin
®
®
econ econ
Miniature linear module, basic version Linear axes with toothed belt
● Single parts made from ● Fast positioning of small loads
aluminium and plastic Order key ● Quiet operation and flat Order key
● Entry-level model design
● Lead screw with plain bearing Order example ● Drive pin on one or both sides Order example
support ● Plastic linear carriage
● Retrofitting possible Options: ● Lightweight due to Options:
● Accessories available Carriage version combination of plastic and Version
u Page 613 aluminium
● Available with motor 03: Basic ● Technical data Toothed belt axis 02: With deep groove
ball bearings
u Page 578
Design
Standard Dimension Carriage version Pitch Installation size Version Design E: econ series
(0630/1040)
l2
hw I + stroke
T
d2 l2 hw H
ha T
d2 H
ha
A
l + Hub
l + stroke A
l + Hub
lt
t Al E2 lt
lb lb
lt lt
t Al E2
lb lb
E1
E1
E3
Øts
E3
Øts
Technical data Dimensions [mm]
Part No. Max. Weight addit. Max. static load capacity Max. Max. drive Part No. A AI H E2 E3 l R f lt sg ha hc lz l2 d2
stroke length [kg] axial radial speed torque -0.3 ±0.15 ±0.15 ±0.15 ±0.3 h9
[mm] [kg] (per 100mm) [N] [N] [rpm] [Nm] ZLW-0630-02 54 60 31 45 51 144 30 3 42 M4 14 22.5 20.5 20 8
SLN-27-03-0008 250 0.06 0.04 10 40 100 0.10 ZLW-1040-02 74 100 44 60 87 204 40 1 52 M6 22 22.5 27 20 10
SLN-27-03-0025 250 0.06 0.04 10 40 100 0.15
SLN-27-03-0051 250 0.06 0.04 10 40 100 0.20 Connecting dimensions [mm]
SLN-27-03-0127 250 0.06 0.04 10 40 100 0.30 Part No. X E AP Lp dp n nb nw nh T1 T2 d
SLN-27-03-0254 250 0.06 0.04 10 40 100 0.40
±0.2 -1.0 ±0.25 ±0.25
ZLW-0630-02 109) variable 40 52 15 5.5 – – 4.3 7 20 21 3.2
Dimensions [mm] ZLW-1040-02 variable 60 78 40 6.4 5.2 9.5 4.3 15.5 36 26.5 5.0
Part No. A AI H E1 E2 E3 E11 102) l hw lt lb ts t T d2 98) l2 ha 109) Basic version: 6mm square, plastic adapter for pin diameter 10mm included
±0.2 -0.1 ±0.2 ±0.15 ±0.15 ±0.15 ±0.2 ±0.2
SLN-27-03-0008 28 35 22 20.5 15 28 15 77 22 21 5.5 3.5 3.2 M5 4 15 14.5
SLN-27-03-0025 28 35 22 20.5 15 28 15 77 22 21 5.5 3.5 3.2 6.35x2.54 5 15 14.5
SLN-27-03-0051 28 35 22 20.5 15 28 15 77 22 21 5.5 3.5 3.2 6.35x5.08 5 15 14.5
SLN-27-03-0127 28 35 22 20.5 15 28 15 77 22 21 5.5 3.5 3.2 6.35x12.7 5 15 14.5
SLN-27-03-0254 28 35 22 20.5 15 28 15 77 22 21 5.5 3.5 3.2 6.35x25.4 5 15 14.5
®
102) The dimension E11 can only be found in conjunction with the igus motor connection
98) Thread/remaining thread visible
ASEAN 09/2023 ASEAN 09/2023
With manual clamp (optional): Part No. SLN-27-HK-...
610 Online tools and more information u www.igus-asean.com/drylinEcon 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinEcon 611
