drylin drive technology | Accessories | Advantages drylin drive technology | Accessories | Product overview
®
®
Secure, reproduce and turn Manual operation, manual positioning

Accessories for

drylin drive
®
Many options
of hand wheels technology - manual
positioning Angular drive Position indicator

● 360° continuously adjustable ● Direct read-out of the carriage position for the lead
Positional An extensive range of accessories is available ● Fixing of setting angle with clamp screw drive
®
indicators for for many drylin drive units to perform manual ● Small flange saves installation space ● Bore reducers included to enable fitting to the entire
different adjustments quickly and conveniently. When u Page 616 product
pitches directly configuring the linear unit with the order, u Page 618
and directions the units are shipped completely assembled. Any
subsequent reconfiguration may result in the lead
screw having to be exchanged because the lead
Variable screw ends may be too short.
display Fast and precise positioning
reading ● Ergonomic operation
directions ●
● Provides a mechanical brake

Available from stock
Detailed information about delivery time online. Lead screw clamp Adapter plate
A lead screw clamp ● For clamping of the lead screw ● Position indicator and/or lead screw clamp
secures the lead screw Price breaks online ● Provides a mechanical brake to the lead screw ● Suitable for linear modules of SHT/SLW/SHTP series
No minimum order value. No minimum order quantity ● Material: polymer housing with aluminium shaft clamp ● Material: plastic igumid G
®
u Page 620 u Page 687

Angular drives for
continuously
adjustable operation

Hand wheels Flex shaft incl. remote control unit
®
● Rotary knob: Defined standard for complete units ● Optional offset operation of the drylin linear modules
● Different outer diameters available ● Controls can be positioned independently
● Different handles available ● Available in length 300, 500 and 1,000mm
u Page 621 ● Can be combined with other accessories
u Page 623
