drylin drylin
®
®
®
®
drive drylin drive technology | Accessories | Product range drylin drive technology | Accessories | Product range drive
technology technology
accessories accessories
Position indicator - safe reproducibility Digital position indicator for even more exact settings
To keep downtime to a minimum and make adjustments quickly, the indicator is used to create repeatable values. These can Order key
be shipped from stock for almost any linear units, in the required counting and viewing direction and in a variety of colours.
Order example
Order key

Order example

● Plastic analogue indicator for adjustment and direct Standard Installation size Display orientation Decimal places Counting direction Housing colour Material
reading of carriage position Installation size Display orientation Decimal places Counting direction Housing colour Pitch
● Counter with 3 (P1), 4 (P3) or 5 (P6) digits (red digit to Standard Material Material
indicate tenths) Pitch The electronic position indicator (battery operated) for Options:
®
● Can be combined with manual clamps and hand wheels drylin linear modules can be programmed by the factory Display orientation
● Reduction sleeves included Options: for the individual thread pitch. Ideal for use with dryspin E02: Standard: Display orientation 0°
®
● Suitable adapter plate available u Page 687 Display orientation Counting direction high helix lead screws. LCD display with 5 digits and special E04: Display orientation rotated by 180°
A: Display orientation 0° DX: clockwise characters, long battery life and easy battery change without
Installation options
B: Display orientation SX: anti-clockwise removal of the device.
180° (optional) Housing colour ● Electronic digital display
Pitch O: Orange ● 5-digit LCD display
< 10.00: One decimal Material ● Features such as incremental adjustment, offset and
place ES: Hollow stainless steel reset, operated via keys on the position indicator
0 degrees 90 degrees 180 degrees 270 degrees > 10.00: No decimal place shaft made from ● Battery life 8 years
Decimal places (optional) ● Battery change without any tools
Display orientation
1: One decimal place ● Increase counting in either direction, clockwise or anti-
(red digit) clockwise
0: No decimal place ● Display orientation standard or through 180°
(red digit)
Note: reduction sleeves included in delivery
A B (optional)
Standard for vertical fitting position:
display turned 180°
Technical data [mm] 66 Technical data

Position Digits Decimal ID hollow Reduction 46 Part No. Rotational speed Weight Temperature Protection class
indicator places shaft sleeves 33 [rpm] [g] [°C]
Ø Ø SHT-P3-E02-2.00-1-DX-O-S 600 60 -10 … +60 IP51
SHT-P1 3 1 8 6 + 6.35 22 32 48
SHT-P3 4 1 14 10 + 12.00
SHT-P6 5 1 20 14 + 16.00
26 33
Dimensions [mm] 50.5

Position H B T
indicator
SHT-P1 33 22 26.0 P1 P3 P6
SHT-P3 46 32 33.0 SLW-0630 all other SHTC-40
SHT-P6 66 48 50.5 SHTP-01-06 linear systems SHTC-50 ASEAN 09/2023 ASEAN 09/2023

618 Online tools and more information u www.igus-asean.com/drylin-accessories 3D CAD files, prices and delivery time online u www.igus-asean.com/drylin-accessories 619
