Configurator for drive technology
Individually configured single axes with electrical drive can
be generated with just a few clicks.
After the parameters are set, connection cables, proximity
switch kits, and control systems can be added.
Winding machine
The requirement for this fabric unwinding system is that
u www.igus-asean.com/DDX
it be lubrication-free with adjustable speeds. igus has
®
the solution with two linear axes running in parallel and
connected to a main shaft.

Configurator for electric motors
After torque and speed is entered, the tool calculates the
motor set that is right for you. Reduction gearboxes are
included in the tool. You can also choose between encoder
and brake.
Cylindrical grinding machine
The customer needs two linear axes for his cylindrical
u www.igus-asean.com/DMX
grinding machine, which can move in the hundredth
range and when wet. A maximum overall length
is also stipulated. The SAW with side installation
in conjunction with an IP65 stepper motor is the
solution for achieving the desired protection class
and maximum overall length.

Configurator for lead screw motors
Our lead screw drive experts help you to find the right linear
actuator quickly and determine predicted service life. You
can choose among four nut categories and different lead
screws.

u www.igus-asean.com/DSE

Pendulum machine
The customer wants to be able to program the parameters
for the school laboratory himself. A higher-level control
system regulates the D1 dryve analogue inputs with an
angular encoder attached to the central pendulum pivot
point and can thus stipulate the position specifications
for erecting the pendulum with the motor.
