drylin drylin | Motors | Accessories drylin | Motors | Accessories drylin
®
®
motors motors
Planetary gear for stepper motors Coupling - vibration dampening and easy fitting
The coupling connects the drive pin of the axis to the
● Planetary gearbox for EC/BLDC and stepper motors motor. An elastic polymer insert in the centre of the
● Increased torque L coupling transfers the motor torque. This damping element
● Higher holding torque compensates for radial and axial clearance.
● Various reduction ratios 20 versions from stock
● Compatible with motors with flange 86 / NEMA34 ØD Ødi1 ●
Ødi2 ● Vibration dampening and pluggable

Coupling material: Aluminium. TPU elastomeric centre. Shore hardness: 98 Sh A. Temperature range -30°C to +100°C.
L1 L1 L L12 L2 L2 B2 B2 B2
B5 B5 B5 L3 L3 L3 L9 L9 L9 Toothed belt axis Motor type Coupling Techn. data - coupling
25 25 25
D di1 di2 L Weight
[mm] [mm] [mm] [kg]
ZLW-0630-B NEMA17 COU-AR-K-050-000-25-26-B-AAAB 25.00 5.00 6.00 26.00 0.02
D2 D1 D2 D1 D2 D1 NEMA23 COU-AR-K-063-000-25-26-B-AAAB 25.00 6.35 6.00 26.00 0.02
D6 D6 D6
DC motor31 COU-AR-K-060-000-25-26-B-AAAB 25.00 6.00 6.00 26.00 0.02
D3 D3 D3
D7 D7 D7 ZLW-0630-S NEMA17 COU-AR-K-050-080-25-26-B-AAAA 25.00 5.00 8.00 26.00 0.02
NEMA23 COU-AR-K-063-080-25-26-B-AAAA 25.00 6.35 8.00 26.00 0.02
DC motor31 COU-AR-K-060-080-25-26-B-AAAA 25.00 6.00 8.00 26.00 0.02
Technical data and dimensions [mm] ZLW-1040-B / ZAW NEMA17 COU-AR-K-050-000-25-26-B-AAAB 25.00 5.00 6.00 26.00 0.02
NEMA23 COU-AR-K-063-000-25-26-B-AAAB 25.00 6.35 6.00 26.00 0.02
Part No. Gear reduction Suitable for Nominal output Drive shaft Weight NEMA23XL COU-AR-K-080-000-25-26-B-AAAB 25.00 8.00 6.00 26.00 0.02
motor size torque diameter
DC motor31 COU-AR-K-060-000-25-26-B-AAAB 25.00 6.00 6.00 26.00 0.02
[Nm] [kg] ZLW-1040-S / ZAW NEMA23 COU-AR-K-063-100-32-32-B-AAAA 32.00 6.35 10.00 32.00 0.05
GEA-60-3-90-ST-140 3 NEMA34 28 140 1.35 NEMA23XL COU-AR-K-080-100-32-32-B-AAAA 32.00 8.00 10.00 32.00 0.05
GEA-60-5-90-ST-140 5 NEMA34 28 140 1.37 NEMA34 COU-AR-K-140-100-32-32-B-AAAA 32.00 14.00 10.00 32.00 0.05
GEA-60-10-90-ST-140 10 NEMA34 40 140 1.40 DC motor31 COU-AR-K-060-100-32-32-B-AAAA 32.00 6.00 10.00 32.00 0.05
GEA-60-15-90-ST-140 15 NEMA34 40 140 1.55 ZLW-1660-S NEMA34 COU-AR-K-140-140-32-32-B-AAAA 32.00 14.00 14.00 32.00 0.05
GEA-60-20-90-ST-140 20 NEMA34 15 140 1.65
GEA-60-40-90-ST-140 40 NEMA34 15 140 1.65 Lead screw axis Motor type Coupling D di1 di2 L Weight
[mm] [mm] [mm] [kg]
SAW-0630 / SLW-BB-0630 NEMA17 COU-AR-K-050-080-25-26-B-AAAA 25.00 5.00 8.00 26.00 0.02
Part No. B1 B2 D1 D2 L1 L2
GEA-60-3-90-ST-140 60 36.7 14 40 35 86 DC motor31 COU-AR-K-060-080-25-26-B-AAAA 25.00 6.00 8.00 26.00 0.02
GEA-60-5-90-ST-140 60 36.7 14 40 35 86 SAW-1040 / SLW-(BB)-1040 NEMA17 COU-AR-K-050-100-32-32-B-AAAA 32.00 5.00 10.00 32.00 0.05
GEA-60-10-90-ST-140 60 36.7 14 40 35 86 NEMA23 COU-AR-K-063-100-32-32-B-AAAA 32.00 6.35 10.00 32.00 0.05
GEA-60-15-90-ST-140 60 36.7 14 40 35 99 NEMA23XL COU-AR-K-080-100-32-32-B-AAAA 32.00 8.00 10.00 32.00 0.05
GEA-60-20-90-ST-140 60 36.7 14 40 35 99 DC motor31 COU-AR-K-060-100-32-32-B-AAAA 32.00 6.00 10.00 32.00 0.05
GEA-60-40-90-ST-140 60 36.7 14 40 35 99 SLW-(BB)-1660 NEMA23 COU-AR-K-063-140-32-32-B-AAAA 32.00 6.35 14.00 32.00 0.05
NEMA23XL COU-AR-K-080-140-32-32-B-AAAA 32.00 8.00 14.00 32.00 0.05
SLW-(BB)-2080 NEMA23 COU-AR-K-063-120-32-32-B-AAAA 32.00 6.35 12.00 32.00 0.05
NEMA23XL COU-AR-K-080-120-32-32-B-AAAA 32.00 8.00 12.00 32.00 0.05
NEMA34 COU-AR-K-140-120-32-32-B-AAAA 32.00 14.00 12.00 32.00 0.05
SHT-(BB)-12 NEMA17 COU-AR-K-050-100-32-32-B-AAAA 32.00 5.00 10.00 32.00 0.05
NEMA23 COU-AR-K-063-100-32-32-B-AAAA 32.00 6.35 10.00 32.00 0.05
NEMA23XL COU-AR-K-080-100-32-32-B-AAAA 32.00 8.00 10.00 32.00 0.05
DC motor31 COU-AR-K-060-100-32-32-B-AAAA 32.00 6.00 10.00 32.00 0.05
SHT-(BB)-20 NEMA23 COU-AR-K-063-120-32-32-B-AAAA 32.00 6.35 12.00 32.00 0.05
8.00 12.00 32.00
NEMA23XL
COU-AR-K-080-120-32-32-B-AAAA 32.00
0.05
ASEAN 09/2023 ASEAN 09/2023 SHT-(BB)-30 NEMA34 COU-AR-K-140-120-32-32-B-AAAA 32.00 14.00 12.00 32.00 0.05
0.05
NEMA34
COU-AR-K-140-140-32-32-B-AAAA 32.00 14.00 14.00 32.00
668 Online tools and more information u www.igus-asean.com/drylinE 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinE 669
