CF11 PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF11
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
6.8 x d ® Oil resistance none 1 2 3 4 highest 6.8 x d
Data cable | TPE | chainflex CF11 Class 6.6.4.1 Torsion none 1 2 3 4 ±360°

12.5 million 6.8 x d 400m Properties and approvals High
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA
z For extremely heavy duty applications Now available 24568 with Plantocut 8 S-MB tested by DEA), Class 4
z TPE outer jacket Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
z Shielded with UL approval 1992)
z Twisted pair & 25% longer Halogen-free Following DIN EN 60754
z Oil and bio-oil-resistant service life
z PVC and halogen-free UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
z Hydrolysis and microbe-resistant service life calculator based on 2 billion test cycles per year"
UL AWM See data sheet for details  www.igus-asean.com/CF11
(from production date 01/2022)
Dynamic information EAC Certificate No. RU C-DE.ME77.B.00300/19
®
Bend radius e-chain linear minimum 6.8 x d
flexible minimum 5 x d REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
fixed minimum 4 x d
®
Temperature e-chain linear -35°C up to +100°C Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
flexible -50°C up to +100°C (following DIN EN 60811-504)
fixed -55°C up to +100°C (following DIN EN 50305) Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
v max. unsupported 10m/s CF9.15.07 - tested by IPA according to standard DIN EN ISO 14644-1
gliding 6m/s CE Following 2014/35/EU
a max. 100m/s²
UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
Travel distance Unsupported travels and up to 400m and more for gliding applications, Class 6

Cable structure Guaranteed service life (details see page 28-29)
Conductor Stranded conductor in especially bending-resistant version consisting of bare Double strokes* 5 million 7.5 million 12.5 million

copper wires (following DIN EN 60228). Temperature, R min. R min. R min.
Core insulation Mechanically high-quality TPE mixture. from/to [°C] [factor x d] [factor x d] [factor x d]
-35/-25 7.5 8.5 9.5
Core structure Cores twisted in pairs with a short pitch length, core pairs then wound with -25/+90 6.8 7.5 8.5
short pitch lengths. +90/+100 7.5 8.5 9.5
Core identification Cores < 1.0mm²: Colour code in accordance with DIN 47100. * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Cores ≥ 1.0mm²: Black cores with white numbers.
®
Inner jacket TPE mixture adapted to suit the requirements in e-chains . Typical application areas
z For heavy-duty applications, Class 6
Overall shield Extremely bending-resistant braiding made of tinned copper wires. z Unsupported travels and up to 400m and more for gliding applications, Class 6
Coverage linear approx. 70%, optical approx. 90% z Almost unlimited resistance to oil, also with bio-oils, Class 4
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, z No torsion, Class 1
adapted to suit the requirements in e-chains . z Indoor and outdoor applications, UV-resistant
®
Colour: Steel blue (similar to RAL 5011) z Storage and retrieval units for high-bay warehouses, machining units/machine tools, quick
Electrical information handling, cleanroom, semiconductor insertion, outdoor cranes, low-temperature applications
Nominal voltage 300/300V (following DIN VDE 0298-3)
300V (following UL)
Testing voltage 1,500V (following DIN EN 50395)

Example image

EPLAN download, configurators  www.igus-asean.com/CF11
