CF113.D PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF113.D
PUR Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PUR
7.5 x d ® Oil resistance none 1 2 3 4 highest 7.5 x d
Measuring system cable | PUR | chainflex CF113.D Class 6.5.3.1 Torsion none 1 2 3 4 ±360°

10 million 7.5 x d 100m Properties and approvals Medium
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 50363-10-2), Class 3
z For extremely heavy duty applications
z PUR outer jacket DriveCliq with Offshore MUD-resistant following NEK 606 - status 2016
z Shielded 300V UL approval
z Oil-resistant and coolant-resistant Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame
z Flame-retardant
z PVC and halogen-free Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
z Notch-resistant 1992)
z Hydrolysis and microbe-resistant Halogen-free Following DIN EN 60754

Dynamic information UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
Bend radius e-chain linear minimum 7.5 x d service life calculator based on 2 billion test cycles per year"
®
flexible minimum 6 x d UL/CSA AWM See data sheet for details  www.igus-asean.com/CF113D
fixed minimum 4 x d
Temperature e-chain linear -25°C up to +80°C NFPA Following NFPA 79-2018, chapter 12.9
®
flexible -40°C up to +80°C (following DIN EN 60811-504)
fixed -50°C up to +80°C (following DIN EN 50305) DNV Type Approval Certificate TAE00003X4
v max. unsupported 10m/s
gliding 5m/s EAC Certificate No. RU C-DE.ME77.B.00295/19
a max. 50m/s²
REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
Travel distance Unsupported travels and up to 100m for gliding applications, Class 5
Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
Cable structure
Conductor Stranded conductor in especially bending-resistant version consisting of tinned Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
copper wires (following DIN EN 60228). CF77.UL.05.12.D - tested by IPA according to standard DIN EN ISO 14644-1
Core insulation Mechanically high-quality TPE mixture. DESINA According to VDW, DESINA standardisation

Core structure According to measuring system specification. CE Following 2014/35/EU

Core identification According to measuring system specification. UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
 Product range table
Element shield Extremely bending-resistant braiding made of tinned copper wires. Guaranteed service life (details see page 28-29)
Coverage linear approx. 70%, optical approx. 90% Double strokes* 5 million 7.5 million 10 million

®
Element shield TPE mixture on pair shielding adapted to suit the requirements in e-chains . Temperature, R min. R min. R min.
from/to [°C] [factor x d] [factor x d] [factor x d]
®
Inner jacket TPE mixture adapted to suit the requirements in e-chains . -25/-15 10 11 12
-15/+70 7.5 8.5 9.5
Overall shield Extremely bending-resistant braiding made of tinned copper wires. +70/+80 10 11 12
Coverage linear approx. 70%, optical approx. 90% * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Outer jacket Low-adhesion, halogen-free, highly abrasion resistant PUR mixture, adapted to
®
suit the requirements in e-chains (following DIN EN 50363-10-2) Typical application areas
Colour: Yellow-green (similar to RAL 6018) z For heavy-duty applications, Class 6
CFRIP ® Strip cables faster: a tear strip is moulded into the inner jacket z z Unsupported travels and up to 100m for gliding applications, Class 5
Almost unlimited resistance to oil, Class 3
Video  www.igus-asean.com/CFRIP
Example image Electrical information 50V z No torsion, Class 1
Nominal voltage
Indoor and outdoor applications without direct sun radiation
z
500V
Testing voltage 300V (following UL) ASEAN2023 ASEAN2023 z Storage and retrieval units for high-bay warehouses, machining units/machine tools, quick
handling, cleanroom, semiconductor insertion, indoor cranes, low temperature applications
262 UL-verified chainflex guarantee ... www.igus-asean.com/ul-verified 263
®
