CF11.D PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF11.D
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
6.8 x d ® Oil resistance none 1 2 3 4 highest 6.8 x d
Measuring system cable | TPE | chainflex CF11.D Class 6.6.4.1 Torsion none 1 2 3 4 ±360°

12.5 million 6.8 x d 400m Properties and approvals Medium
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA
z For extremely heavy duty applications Now available 24568 with Plantocut 8 S-MB tested by DEA), Class 4
z TPE outer jacket Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
z Shielded with UL approval 1992)
z Oil and bio-oil-resistant & 25% longer Halogen-free Following DIN EN 60754
z PVC and halogen-free service life
z Hydrolysis and microbe-resistant UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
service life calculator based on 2 billion test cycles per year"
Dynamic information UL AWM See data sheet for details  www.igus-asean.com/CF11D
®
Bend radius e-chain linear minimum 6.8 x d
flexible minimum 5 x d EAC Certificate No. RU C-DE.ME77.B.00295/19
fixed minimum 4 x d
®
Temperature e-chain linear -35°C up to +90°C REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
flexible -50°C up to +90°C (following DIN EN 60811-504)
fixed -55°C up to +90°C (following DIN EN 50305) Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
v max. unsupported 10m/s
gliding 6m/s Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
a max. 100m/s² CF9.15.07 - tested by IPA according to standard DIN EN ISO 14644-1
DESINA According to VDW, DESINA standardisation
Travel distance Unsupported travels and up to 400m and more for gliding applications, Class 6
CE Following 2014/35/EU
Cable structure
Conductor Stranded conductor in especially bending-resistant version consisting of tinned UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
copper wires (following DIN EN 60228).
Core insulation Mechanically high-quality TPE mixture.
Guaranteed service life (details see page 28-29)
Core structure According to measuring system specification. Double strokes* 5 million 7.5 million 12.5 million

< 10m ≥ 10m < 10m ≥ 10m < 10m ≥ 10m
Core identification According to measuring system specification. Temperature, R min. R min. R min. R min. R min. R min.
 Product range table from/to [°C] [factor x d] [factor x d] [factor x d] [factor x d] [factor x d] [factor x d]
Element shield Extremely bending-resistant braiding made of tinned copper wires. -35/-25 8.5 10 9.5 11 10.5 12
Coverage linear approx. 70%, optical approx. 90% -25/+80 6.8 7.5 7.5 8.5 8.5 9.5
®
Element shield TPE mixture on pair shielding adapted to suit the requirements in e-chains . +80/+90 8.5 10 9.5 11 10.5 12
* Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
®
Inner jacket TPE mixture adapted to suit the requirements in e-chains .
Typical application areas
Overall shield Extremely bending-resistant braiding made of tinned copper wires. z For heavy-duty applications, Class 6
Coverage linear approx. 70%, optical approx. 90% z Unsupported travels and up to 400m and more for gliding applications, Class 6
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, z Almost unlimited resistance to oil, also with bio-oils, Class 4
adapted to suit the requirements in e-chains . z No torsion, Class 1
®
Colour: Yellow-green (similar to RAL 6018) z Indoor and outdoor applications without direct sun radiation
CFRIP ® Strip cables faster: a tear strip is moulded into the inner jacket z Storage and retrieval units for high-bay warehouses, machining units/machine tools, quick
Video  www.igus-asean.com/CFRIP handling, cleanroom, semiconductor insertion, indoor cranes, low temperature applications
Electrical information 50V
Example image Testing voltage 300V (following UL)
Nominal voltage
500V

ASEAN2023 ASEAN2023

268 36-month guarantee ... more than 1,350 cable types from stock ... no cutting charges UL-verified chainflex guarantee ... www.igus-asean.com/ul-verified 269
®
