CF895 PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF895
iguPUR Travel distance unsupported 1 2 3 4 5 6 ≥ 400m iguPUR
15 x d ® Oil resistance none 1 2 3 4 highest 15 x d
Motor cable | iguPUR | chainflex CF895 Class 3.1.3.1 Torsion none 1 2 3 4 ±360°

5 million 15 x d 10m Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
1992)
z For flexing applications UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
z iguPUR outer jacket service life calculator based on 2 billion test cycles per year"
z Oil-resistant UL/CSA AWM See data sheet for details  www.igus-asean.com/CF895
z Flame-retardant
NFPA Following NFPA 79-2018, chapter 12.9

Dynamic information EAC Certificate No. RU C-DE.ME77.B.00302/19
Bend radius e-chain linear minimum 15 x d
®
flexible minimum 12 x d REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
fixed minimum 8 x d
®
Temperature e-chain linear -20°C up to +80°C Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
flexible -40°C up to +80°C (following DIN EN 60811-504)
fixed -50°C up to +80°C (following DIN EN 50305) CE Following 2014/35/EU
v max. unsupported 3m/s
UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
a max. 20m/s²

Travel distance Unsupported travels up to 10m, Class 1 Guaranteed service life (details see page 28-29)

Double strokes* 1 million 3 million 5 million
Cable structure Temperature, R min. R min. R min.
Conductor Conductor consisting of bare copper wires (according to DIN EN 60228). from/to [°C] [factor x d] [factor x d] [factor x d]
-20/-10 17.5 18.5 19.5
Core insulation Mechanically high-quality, especially low-capacitance TPE mixture. -10/+70 15 16 17
+70/+80 17.5 18.5 19.5
Core structure Cores wound with an optimised pitch length. * Higher number of double strokes? Service life calculation online www.igus-asean.com/chainflexlife

Core identification Black cores with white numbers, one green-yellow core. Typical application areas
1. Core: U / L1 / C / L+ z For flexing applications, Class 3
2. Core: V / L2 z Especially for unsupported travels, Class 1
3. Core: W / L3 / D / L- z With influence of oil, Class 3
Outer jacket Low-adhesion iguPUR mixture, adapted to suit the requirements in e-chains . z No torsion, Class 1
®
Colour: Pastel orange (similar to RAL 2003) z Indoor and outdoor applications without direct sun radiation
z Machining units/machine tools, low temperature applications
Electrical information
Nominal voltage 600/1,000V (following DIN VDE 0298-3)
1,000V (following UL) Part No. Number of cores and conductor Outer diameter Copper Weight
Testing voltage 4,000V (following DIN EN 50395) nominal cross section (d) max. index
[mm²] [mm] [kg/km] [kg/km]
Properties and approvals CF895.15.04 4G1.5 8.0 67 101
UV resistance Medium CF895.25.04 4G2.5 10.0 110 153
CF895.40.04 4G4.0 11.5 175 239
Oil resistance Oil-resistant (following DIN EN 50363-10-2), Class 3 CF895.60.04 4G6.0 13.5 262 353
CF895.100.04 4G10 17.0 436 543
20.0
4G16
653
824
CF895.160.04
Example image Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
EPLAN download, configurators  www.igus-asean.com/CF895
