CF270.UL.D PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF270.UL.D
PUR Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PUR
10 x d ® Oil resistance none 1 2 3 4 highest 10 x d
Motor cable | PUR | chainflex CF270.UL.D Class 4.2.3.1 Torsion none 1 2 3 4 ±360°

10 million 10 x d 10m Properties and approvals Medium
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 50363-10-2), Class 3
z For medium duty applications z Notch-resistant
z PUR outer jacket z Flame-retardant Offshore MUD-resistant following NEK 606 - status 2016
z Shielded z Hydrolysis and microbe-resistant
z Oil-resistant and coolant-resistant z PVC and halogen-free Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame

Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
Dynamic information 1992)
®
Bend radius e-chain linear minimum 10 x d Halogen-free Following DIN EN 60754
flexible minimum 8 x d
fixed minimum 5 x d UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
®
Temperature e-chain linear -25°C up to +80°C service life calculator based on 2 billion test cycles per year"
flexible -40°C up to +80°C (following DIN EN 60811-504) UL/CSA AWM See data sheet for details  www.igus-asean.com/CF270ULD
fixed -50°C up to +80°C (following DIN EN 50305)
v max. unsupported 10m/s NFPA Following NFPA 79-2018, chapter 12.9
gliding 2m/s
a max. 50m/s² EAC Certificate No. RU C-DE.ME77.B.00863/20

Travel distance Unsupported travels and up to 10m for gliding applications, Class 2 REACH In accordance with regulation (EC) No. 1907/2006 (REACH)

Cable structure Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
Conductor Stranded conductor in bending-resistant version consisting of bare copper
wires (following DIN EN 60228). Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
Core insulation Mechanically high-quality, especially low-capacitance XLPE mixture. CF77.UL.05.12.D - tested by IPA according to standard DIN EN ISO 14644-1
DESINA According to VDW, DESINA standardisation
Core structure Cores wound with high tensile strength centre elements.
CE Following 2014/35/EU
Core identification Black cores with white numbers, one green-yellow core.
1. Core: U / L1 / C / L+ UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
2. Core: V / L2
3. Core: W / L3 / D / L-
Intermediate layer Foil taping over the outer layer. Guaranteed service life (details see page 28-29)
Double strokes* 5 million 7.5 million 10 million

Overall shield Bending-resistant braiding made of tinned copper wires. Temperature, R min. R min. R min.
Coverage linear approx. 55%, optical approx. 80% from/to [°C] [factor x d] [factor x d] [factor x d]
Outer jacket Low-adhesion, halogen-free, highly abrasion resistant PUR mixture, adapted -25/-15 12.5 13.5 14.5
to suit the requirements in e-chains (following DIN EN 50363-10-2) -15/+70 10 11 12
®
Colour: Pastel orange (similar to RAL 2003) +70/+80 12.5 13.5 14.5
* Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Electrical information
Nominal voltage 600/1,000V (following DIN VDE 0298-3) Typical application areas
1,000V (following UL) z For medium duty applications, Class 4
Testing voltage 4,000V (following DIN EN 50395) z Unsupported travels and up to 10m for gliding applications, Class 2
z Almost unlimited resistance to oil, Class 3
No torsion, Class 1
Example image z Indoor and outdoor applications without direct sun radiation
z
Machining units/machine tools, low temperature applications
z
EPLAN download, configurators  www.igus-asean.com/CF270ULD
