Page 348 - ASEAN Chainflex Catalogue 2023

CF27.D PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF27.D
PUR Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PUR
7.5 x d ® Oil resistance none 1 2 3 4 highest 7.5 x d
Motor cable | PUR | chainflex CF27.D Class 6.5.3.1 Torsion none 1 2 3 4 ±360°

Strip cables 50% faster with CFRIP tear strip
®

Example image

Number of cores and conductor Outer diameter Copper Order example: CF27.07.04.D – to your desired length (0.5m steps)
Part No. Weight
nominal cross section (d) max. index CF27.D chainflex series .07 Code nominal cross section .04 Number of cores
®
[mm²] [mm] [kg/km] [kg/km]
CF27.07.04.D (4G0.75)C 9.5 55 115 Order online  www.igus-asean.com/CF27D
CF27.15.04.D (4G1.5)C 11.0 90 165
CF27.25.04.D (4G2.5)C 12.5 135 231 Delivery time 24hrs or today.
CF27.500.04.D (4G50)C 37.0 2244 2817 Delivery time means time until goods are shipped.
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core

Cables available in the chainflex CASE Reduce cost, improve technology, now!
®
®
Simple savings on delivery, storage space and re-ordering with Do the chainflex price check ...
®
®
the chainflex CASE - ship'n store by igus . www.igus-asean.com/cf-price-check
More on this on page 24/25 and online: www.igus-asean.com/cf-case
... here's an idea for you: highest abrasion resistance with CF38 ...

®
Modular design, easy to retrofit: igus E4 e-chain and chainflex cables.
®
®

EPLAN download, configurators  www.igus-asean.com/CF27D

342 36-month guarantee ... more than 1,350 cable types from stock ... no cutting charges ASEAN2023 ASEAN2023 UL-verified chainflex guarantee ... www.igus-asean.com/ul-verified 343
®
