CF37.D PVC iguPUR PUR TPE Now available with Basic requirements low 1 2 3 4 5 6 7 highest CF37.D
TPE UL approval & 25% Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
7.5 x d ® Oil resistance none 1 2 3 4 highest 7.5 x d
Motor cable | TPE | chainflex CF37.D longer service life Class 7.6.4.2 Torsion none 1 2 3 4 ±360°

12.5 million 7.5 x d 400m Halogen-free Following DIN EN 60754
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
service life calculator based on 2 billion test cycles per year"
z For heaviest duty applications z UV-resistant UL AWM See data sheet for details  www.igus-asean.com/CF37D
z TPE outer jacket z Hydrolysis and microbe-resistant
z Oil and bio-oil-resistant EAC Certificate No. RU C-DE.ME77.B.00863/20
z PVC and halogen-free
REACH In accordance with regulation (EC) No. 1907/2006 (REACH)

Dynamic information Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
®
Bend radius e-chain linear minimum 7.5 x d
flexible minimum 6 x d Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
fixed minimum 4 x d CF9.15.07 - tested by IPA according to standard DIN EN ISO 14644-1
Temperature e-chain linear -35°C up to +90°C DESINA According to VDW, DESINA standardisation
®
flexible -50°C up to +90°C (following DIN EN 60811-504)
fixed -55°C up to +90°C (following DIN EN 50305) CE Following 2014/35/EU
v max. unsupported 10m/s
gliding 6m/s UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
a max. 80m/s²
Guaranteed service life (details see page 28-29)
Travel distance Unsupported travels and up to 400m and more for gliding applications, Class 6 Double strokes* 5 million 7.5 million 12.5 million

Temperature, R min. R min. R min.
Torsion Torsion ±90°, with 1m cable length, Class 2 from/to [°C] [factor x d] [factor x d] [factor x d]
-35/-25 10 11 12
Cable structure -25/+80 7.5 8.5 9.5
Conductor Cores <10mm²: Stranded conductor in especially bending-resistant version +80/+90 10 11 12
consisting of bare copper wires (following DIN EN 60228). * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Cores ≥ 10mm²: Conductor cable consisting of pre-leads (following DIN EN 60228).
Core insulation Mechanically high-quality, especially low-capacitance XLPE mixture. Typical application areas
z For heavy-duty applications, Class 7
Core structure Cores wound with a short pitch length around a high tensile strength centre z Unsupported travels and up to 400m and more for gliding applications, Class 6
element. z Almost unlimited resistance to oil, also with bio-oils, Class 4
Core identification Black cores with white numbers, one green-yellow core. z Torsion ±90°, with 1m cable length, Class 2
1. Core: U / L1 / C / L+ 2. Core: V / L2 z Indoor and outdoor applications, UV-resistant
3. Core: W / L3 / D / L- 4. Core: 4 / N z Storage and retrieval units for high-bay warehouses, machining units/machine tools, quick
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, handling, cleanroom, semiconductor insertion, outdoor cranes, low-temperature applications
®
adapted to suit the requirements in e-chains .
Colour: jet black (similar to RAL 9005) Part No. Number of cores and conductor Outer diameter Copper Weight
CFRIP ® Strip cables faster: a tear strip is moulded into the outer jacket nominal cross section (d) max. index
Video  www.igus-asean.com/CFRIP [mm²] [mm] [kg/km] [kg/km]
Electrical information CF37.15.04.D 4G1.5 8.0 61 95
Nominal voltage 600/1,000V (following DIN VDE 0298-3) CF37.25.04.D 4G2.5 10.0 100 149
1,000V (following UL) CF37.40.04.D 4G4.0 11.5 163 221
Testing voltage 4,000V (following DIN EN 50395) CF37.60.04.D 4G6.0 13.5 237 317
CF37.60.05.D 5G6.0 15.0 297 387
Properties and approvals High CF37.100.04.D 4G10 16.5 407 503
515
634
19.0
5G10
CF37.100.05.D
Example image Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA CF37.160.04.D 4G16 20.0 646 773
UV resistance
5G16
22.5
815
963
CF37.160.05.D
1530
CF37.500.03.O.PE.D
30.0
1826
3x50
Silicone-free 24568 with Plantocut 8 S-MB tested by DEA), Class 4 ASEAN2023 ASEAN2023 CF37.250.04.D 11) 4G25 24.0 1014 1203
Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
352 1992) 11) Phase-out model Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. 353
G = with green-yellow earth core x = without earth core
