CF885 PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF885
PVC Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PVC
15 x d ® Oil resistance none 1 2 3 4 highest 15 x d
Spindle cable/Single core | PVC | chainflex CF885 Class 3.1.1.1 Torsion none 1 2 3 4 ±360°

5,000,000 15 x d 10m Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
CE Following 2014/35/EU

z For flexing applications UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
z PVC outer jacket
z Flame-retardant
Guaranteed service life (details see page 28-29)
Double strokes* 1 million 3 million 5 million

Dynamic information Temperature, R min. R min. R min.
®
Bend radius e-chain linear minimum 15 x d from/to [°C] [factor x d] [factor x d] [factor x d]
flexible minimum 12 x d +5/+15 17.5 18.5 19.5
fixed minimum 8 x d +15/+60 15 16 17
®
Temperature e-chain linear +5°C up to +70°C +60/+70 17.5 18.5 19.5
flexible -5°C up to +70°C (following DIN EN 60811-504) * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
fixed -15°C up to +70°C (following DIN EN 50305)
v max. unsupported 3m/s Typical application areas
z For flexing applications, Class 3
a max. 20m/s² z Especially for unsupported travels, Class 1
z Without influence of oil, Class 1
Travel distance Unsupported travels up to 10m, Class 1 z No torsion, Class 1
z Preferably indoor applications
Cable structure z Wood/stone processing, packaging industry, feeding, handling, adjusting devices
Conductor Conductor consisting of bare copper wires (according to DIN EN 60228).
Number of cores and conductor Outer diameter Copper
Part No. Weight
Core insulation Mechanically high-quality PVC mixture. nominal cross section (d) max. index
[mm²] [mm] [kg/km] [kg/km]
Outer jacket Low-adhesion PVC mixture, adapted to suit the requirements in e-chains . CF885.40.01 1x4.0 7.5 41 78
®
Colour: Pastel orange (similar to RAL 2003) CF885.60.01 1x6.0 8.0 61 100
CF885.100.01 1x10 9.5 100 157

Electrical information CF885.160.01 1x16 11.5 159 237
Nominal voltage 600/1,000V (following DIN VDE 0298-3) CF885.250.01 1x25 12.5 248 325
600V (following UL) CF885.350.01 1x35 15.0 347 474
Testing voltage 4,000V (following DIN EN 50395) CF885.500.01 1x50 16.5 495 644
CF885.700.01 1x70 18.5 686 844

Properties and approvals CF885.950.01 1x95 20.5 931 1024
Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core

Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
1992) Cables available in the chainflex CASE
®
UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and Simple savings on delivery, storage space and re-ordering with
service life calculator based on 2 billion test cycles per year" the chainflex CASE - ship'n store by igus .
®
®
UL/CSA AWM See data sheet for details  www.igus-asean.com/CF885
More on this on page 24/25 and online: www.igus-asean.com/cf-case
NFPA Following NFPA 79-2018, chapter 12.9

EAC Certificate No. RU C-DE.ME77.B.00302/19
Example image REACH In accordance with regulation (EC) No. 1907/2006 (REACH)

EPLAN download, configurators  www.igus-asean.com/CF885
